Sharp CD-C602

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C602,CPC602
SW608(257-11) 92LM-SW1658A J AB Switch,Leaf Type [Tape 1 Play]
SW701 92LSWICHT1663T J AC Switch,Key Type [Power]
SW702 92LSWICHT1663T J AC Switch,Key Type [Volume Up]
SW703 92LSWICHT1663T J AC Switch,Key Type [Volume Down]
SW704 92LSWICHT1663T J AC Switch,Key Type [Play]
SW705 92LSWICHT1663T J AC Switch,Key Type [Fast Forward]
SW706 92LSWICHT1663T J AC Switch,Key Type [Rewind]
SW707 92LSWICHT1663T J AC Switch,Key Type [Open/Close]
SW708 92LSWICHT1663T J AC Switch,Key Type [Stop]
SW709 92LSWICHT1663T J AC Switch,Key Type [Disc Skip]
SW710 92LSWICHT1663T J AC Switch,Key Type [X-BASS]
SW711 92LSWICHT1663T J AC Switch,Key Type [Function]
SW712 92LSWICHT1663T J AC Switch,Key Type [Band]
SW714 92LSWICHT1663T J AC Switch,Key Type [Memory]
SW715 92LSWICHT1663T J AC Switch,Key Type [Tuning Up]
SW716 92LSWICHT1663T J AC Switch,Key Type [Tuning Down]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LMCUSN1524A J AD Cushion
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERH0010AWZZ J AB Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1854CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
CABINET PARTS
201 92LCAB3037AS1 J AX Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 HDECQ0446AWSA J AG Panel,LCD Display
201- 3 GCOVA1204AWSA J AD Cover,Remote Sensor
202 GITAR0427AWSA J AG Back Board [For U.S.A.]
202 GITAR0428AWSA J Back Board
[For Central America]
202 GITAR0430AWSA J Back Board [For Canada]
203 GITAS0035AWSC J AK Side Panel,Left
204 GITAS0036AWSC J AH Side Panel,Right
205 GCAB-1046AWSC J AP Top Cabinet
206 GCOVA1231AWSA J AM Cover,CD Tray
207 92LLABL1784F J AC Label,UL Caution
208 92LCSPR1596A J AA Spring,Cassette Holder Up
209 JBTN-0126AWSA J AE Button,Record [Tape 1]
210 JBTN-0127AWSA J AE Button,Play [Tape 1]
211 JBTN-0128AWSA J AE Button,Rewind [Tape 1]
212 JBTN-0129AWSA J AE Button,Fast Forward [Tape 1]
213 JBTN-0130AWSA J AE Button,Stop/Eject [Tape 1]
214 JBTN-0131AWSA J AE Button,Play [Tape 2]
215 LCHSM0054AWSA J AH Main Chassis
217 JBTN-0132AWSA J AE Button,Stop/Eject [Tape 2]
218 PRDAR0131AWFW J AG Heat Sink
220 MSPRD0044AWFJ J AB Spring,Lock Lever
221 MLEVP0067AWZZ J AC Lever,Lock
222 NROLP0009AWZZ J AB Roller
223 LCHSZ0010AWZZ J AM Chassis,Loading
224 MLEVP0070AWZZ J AB Lever,Turntable Lock
225 MSPRC0020AWFJ J AB Spring,Turntable Lock Lever
226 GCAB-1044AWSA J AM CD Player Base
228 LHLDZ1139AWSA J AD Support,Stabilizer
229 92LHOLD2037AS1 J AK Stabilizer Ass’y
229- 1 ———— — Stabilizer
(Not Replacement Item)
229- 2 PMAGF0001AWZZ J AF Magnet
229- 3 92LSUPT1749D J AA Support,Magnet
230 NTNT-0018AWSA J AK Turntable
231 LHLDZ1140AWZZ J AB Guide
232 MLEVP0068AWZZ J AB Lever,Change
233 MSPRC0024AWFW J AB Spring,Solenoid
234 LCHSZ0011AWZZ J AG Chassis,CD Mechanism
235 NGERK0004AWZZ J AB Gear,Bevel
237 NGERW0006AWZZ J AC Gear,Worm Wheel
238 NPLYD0001AWZZ J AB Pulley
239 NGERK0005AWZZ J AB Gear,Loading
240 MLEVP0066AWZZ J AE Lever,Shift
241 NGERH0064AWZZ J AD Gear,Cam
242 NGERK0003AWZZ J AC Gear,Drive
243 LHLDZ1141AWZZ J AB Support,Pitch
244 NGERH0065AWZZ J AB Gear,Turntable
245 NBLTK0029AWZZ J AB Belt,Drive
246 92LN-BAND1318A J AA Nylon Band,80mm
247(SOLM2) RPLU-0002AWZZ J AH Solenoid Ass’y
248 92LCOV3037CTS1 J AK Cassette Cover Ass’y,Tape 1
248- 1 ———— — Cassette Cover,Tape 1
(Not Replacement Item)
248- 2 HDECQ0447AWSA J AD Panel,Cassette Cover,Tape 1
249 92LCOV3037CTS2 J AK Cassette Cover Ass’y,Tape 2
249- 1 ———— — Cassette Cover,Tape 2
(Not Replacement Item)
249- 2 HDECQ0448AWSA J AD Panel,Cassette Cover,Tape 2
250 MLIFP0001AWSA J AG Damper
251 JKNBZ0591AWSA J AG Button,Stop
252 JKNBZ0590AWSA J AG Button,Function
253 JKNBZ0587AWSA J AG Button,Volume Up/Down
254 JKNBZ0588AWSA J AF Button,X-BASS
255 JKNBZ0589AWSA J AG Button,Power/Function/Tuning
Up/Down
257 92LMECHA3037A J BH Tape Mechanism Ass’y
257- 1 92LM-BELT1651B J AB FF/REW Belt
257- 2 92LMBELT1658A1 J AC Belt,Drive [Tape 1]
257- 3 92LMBELT1658B1 J AC Drive Belt [Tape 2]
257- 4 92LM-EH1658A J AG Head,Erase
257- 5 92LM-PRA1651A J AE Pinch Roller Ass’y
257- 6 92LM-RPH1746A J AM Head,Record/Playback
257- 7(M601) RMOTM0004AWM1 J AR Motor with Pulley [Tape]
257- 8(SW605) 92LM-SW1491A J AE Switch,Leaf Type [Tape 1 Main]
257- 9(SW606) 92LM-SW1491A J AE Switch,Leaf Type [Tape 2 Main]
257-10(SW607) 92LM-SW1658A J AB Switch,Leaf Type
[Tape 1 Record]
257-11(SW608) 92LM-SW1658A J AB Switch,Leaf Type [Tape 1 Play]
259 TLABS0058AWZZ J AB Label,UL Shinca Jitra
260 TLABS0155AWZZ J AC Label,UL Team Concepts
! 261 QLUGP0001AWZZ J AC Terminal,Lug
262 GDORF0060AWSA J AF Cassette Holder,Tape 1
263 GDORF0061AWSA J AF Cassette Holder,Tape 2
264 XWHJZ62-09510 J AB Washer,ø6.2×ø10×0.9mm
265 LANGF0032AWZZ J AC Support,Turntable Lock Lever
266 PCUSG0022AWZZ J AB Cushion,Foot
267 TLABN0086AWZZ J AB Label,Production SER.No.
[U.S.A. Only]
268 92LLABL372C J AB Label,Serial No.
[For Canada/Central America
Only]
269 PCOVZ1013AWZZ J AB Cover,Wire
601 XEBSD30P10000 J AA Screw,ø3×10mm
602 XESSD30P10000 J AA Screw,ø3×10mm
603 XEBSD30P12000 J AA Screw,ø3×12mm
605 XEBSF30P12000 J AA Screw,ø3×12mm
606 LX-JZ0004AWFD J AA Screw,ø3×12mm
607 LX-JZ0002AWFD J AA Screw,ø3×10mm
608 LX-EZ0005AWFD J AA Screw,ø2.6×10mm
609 XJSSF30P10000 J AA Screw,ø3×10mm
610 XBPSD26P05JSO J AB Screw,ø2.6×5mm
611 LX-TZ0019AFZZ J AB Screw,Special
612 XEBSD26P12000 J AA Screw,ø2.6×12mm
613 XJBSF30P08000 J AA Screw,ø3×8mm
614 XJBSD30P08000 J AA Screw,ø3×8mm
615 XWHSD32-10130 J AA Washer,Power Transformer
PACKING PARTS (For Canada/Central America)
SPAKA0196AWZZ J AN Packing Add.,Left/Right
SPAKC0733AWZZ J AS Packing Case
[For Central America]
SPAKC0750AWZZ J Packing Case [For Canada]
SPAKP0013AWZZ1 J AC Polyethylene Bag,Unit
SPAKZ0292AWZZ J AB Mirror Mat
TLABR1029AWZZ J AB Label,Bar Code
[For Central America Only]
92LBAG1460C1 J AB Polyethylene Bag,Accessories
– 4 –
