CD-C605H
– 3 –
Specifications for this model are subject to change without prior
notice.
CD-C605H
CP-C605H
SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
● General
Power source: AC 230 V, 50 Hz
Power consumption: 40 W
Dimensions: Width; 270 mm (10-5/8")
Height; 300 mm (11-13/16")
Depth; 353 mm (13-7/8")
Weight: 5.1 kg (11.2 lbs)
● Amplifier section
Output power: PMPO; 66 W
MPO; 33W (16.5 W + 16.5 W)
(DIN 45 324)
RMS; 20 W (10 W + 10 W)
(DIN 45 324)
RMS; 16 W (8 W + 8 W)
(DIN 45 500)
Output terminals: Speakers; 8 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
● Tuner section
Frequency range: FM; 87.5-108 MHz
AM; 522-1,620 kHz
● Cassette deck section
Frequency response: 50 - 14,000 Hz (Normal tape)
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter: 0.20 % (DIN 45 511)
● Compact disc player section
Type: 3-disc multi-play compact disc player
Signal readout: Non-contact, 3-beam semiconductor
laser pickup
D/A converter: 1-bit D/A converter
Frequency response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz)
● Speaker section
Type: 10cm (4") full-range speaker
Maximum input
power: 20 W
Impedance: 8 ohms
Dimensions: Width; 180 mm (7-1/8")
Height; 300 mm (11-13/16")
Depth; 204 mm (8-1/10")
Weight: 2.0 kg (4.4 lbs)/each
