CD-C605H
R556 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R557 VRD-MN2BD120J J AA 12 ohms,1/8W
R561 VRD-ST2CD223J J AA 22 kohms,1/6W
R601 VRD-ST2CD561J J AA 560 ohms,1/6W
R602 VRD-MN2BD561J J AA 560 ohms,1/8W
R603,604 VRD-ST2CD333J J AA 33 kohms,1/6W
R605 VRD-ST2CD121J J AA 120 ohms,1/6W
R606,607 VRD-ST2CD102J J AA 1 kohm,1/6W
R608 VRD-ST2CD121J J AA 120 ohms,1/6W
R609,610 VRD-RT2HD271J J AA 270 ohms,1/2W
R611,612 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R613,614 VRD-ST2EE331J J AA 330 ohms,1/4W
R631 VRD-ST2CD223J J AA 22 kohms,1/6W
R632 VRD-ST2EE821J J AA 820 ohms,1/4W
R633 VRD-ST2CD563J J AA 56 kohms,1/6W
R651~654 VRD-ST2EE3R3J J AA 3.3 ohms,1/4W
R701 VRD-MN2BD102J J AA 1 kohm,1/8W
R702 VRD-MN2BD102J J AA 1 kohm,1/8W
R703 VRD-MN2BD102J J AA 1 kohm,1/8W
R704~708 VRD-MN2BD102J J AA 1 kohm,1/8W
R709 VRD-ST2CD102J J AA 1 kohm,1/6W
R710,711 VRD-MN2BD102J J AA 1 kohm,1/8W
R712 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R713 VRD-MN2BD102J J AA 1 kohm,1/8W
R714 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R715 VRD-MN2BD102J J AA 1 kohm,1/8W
R716 VRD-ST2CD102J J AA 1 kohm,1/6W
R717~719 VRD-MN2BD102J J AA 1 kohm,1/8W
R721~724 VRD-MN2BD102J J AA 1 kohm,1/8W
R725 VRD-MN2BD102J J AA 1 kohm,1/8W
R726 VRD-ST2CD102J J AA 1 kohm,1/6W
R727 VRD-MN2BD102J J AA 1 kohm,1/8W
R728,729 VRD-ST2CD102J J AA 1 kohm,1/6W
R730 VRD-MN2BD102J J AA 1 kohm,1/8W
R731~734 VRD-MN2BD102J J AA 1 kohm,1/8W
R735,736 VRD-ST2CD102J J AA 1 kohm,1/6W
R737,738 VRD-ST2CD102J J AA 1 kohm,1/6W
R739 VRD-MN2BD103J J AA 10 kohm,1/8W
R740 VRD-MN2BD103J J AA 10 kohm,1/8W
R741 VRD-ST2CD104J J AA 100 kohm,1/6W
R742 VRD-MN2BD103J J AA 10 kohm,1/8W
R743 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R745 VRD-MN2BD103J J AA 10 kohm,1/8W
R746,747 VRD-ST2CD103J J AA 10 kohm,1/6W
R748 VRD-MN2BD103J J AA 10 kohm,1/8W
R749 VRD-ST2CD103J J AA 10 kohm,1/6W
R750~752 VRD-MN2BD103J J AA 10 kohm,1/8W
R753,754 VRD-MN2BD103J J AA 10 kohm,1/8W
R755 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R756,757 VRD-ST2CD103J J AA 10 kohm,1/6W
R758 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R760 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R761 VRD-ST2CD821J J AA 820 ohms,1/6W
R762 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R763 VRD-MN2BD821J J AA 820 ohms,1/8W
R764 VRD-ST2CD821J J AA 820 ohms,1/6W
R765 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R766 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R767 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R768 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R770,771 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R772 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R773,774 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R775 VRD-MN2BD102J J AA 1 kohm,1/8W
R776,777 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R778 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R780 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R782 VRD-ST2CD473J J AA 47 kohms,1/6W
R783 VRD-ST2CD104J J AA 100 kohm,1/6W
R785 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R786 VRD-ST2CD101J J AA 100 ohm,1/6W
R791 VRD-MN2BD102J J AA 1 kohm,1/8W
R792 VRD-ST2CD330J J AA 33 ohms,1/6W
R793 VRD-ST2CD274J J AA 270 kohms,1/6W
R800 VRD-RT2HD100J J AA 10 ohm,1/2W
R901 VRD-ST2CD103J J AA 10 kohm,1/6W
R902 VRD-RT2HD221J J AA 220 ohms,1/2W
R903 VRD-ST2CD123J J AA 12 kohms,1/6W
R904 VRD-RT2HD221J J AA 220 ohms,1/2W
R905 VRD-ST2CD101J J AA 100 ohm,1/6W
R906 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R908 VRD-ST2CD221J J AA 220 ohms,1/6W
OTHER CIRCUITRY PARTS
BI401/CNS401 QCNWN1380AWZZ J AF Connector Ass’y,6/6Pin
BI701/CNS701 QCNWN1381AWZZ J AL Connector Ass’y,15/15Pin
BI702/CNS702 QCNWN0907AWZZ J AC Connector Ass’y,8/12Pin
BIM5/CNS10/CNS5 QCNWN1184AWZZ J AL Connector Ass’y,6/10/2Pin
CNP1 92LCONE5P53253 J AB Plug,5Pin
CNP2 QCNCM705HAFZZ J AB Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP10 QCNCM705KAWZZ J AC Plug,10Pin
CNP11 QCNCM704FAWZZ J AC Plug,6Pin
CNP12 QCNCM704QAWZZ J AG Plug,15Pin
CNP301 92LCONE-2P5268 J AB Plug,2Pin
CNP303 QCNCW010JAWZZ J Plug,9Pin
CNP501 92LCONE3P5267X J AB Plug,3Pin
CNP502 92LCONE7P5267X J AC Plug,7Pin
CNP901 QCNCM036BAWZZ J AC Plug,2Pin
CNP902 QCNCM035FAWZZ J AC Plug,6Pin
CNPM1 QCNCM932MAFZZ J AE Plug,12Pin
CNPM2 QCNCM030BAWZZ J AB Pin Header,2Pin
CNS1A/B QCNWN1181AWZZ J AK Connector Ass’y,5/5Pin
CNS2A/B QCNWN1182AWZZ J AH Connector Ass’y,8/8Pin
CNS3A/B QCNWN1183AWZZ J AG Connector Ass’y,6/6Pin
CNS101 QCNWN0895AWZZ J AE Connector Ass’y,3Pin
CNS102 QCNWN0896AWZZ J AG Connector Ass’y,8Pin
CNS303 QCNCM010JAWZZ J Plug,9Pin
! F901 92LFUSET252E J AD Fuse,T2.5A L 250V
! F902 92LFUSE-T162-E J AD Fuse,T1.6A L 250V
! F903 92LFUSE-T501E J AD Fuse,T500mA L 250V
FE301 RTUNS0012AWZZ J AV FM Front End
FL701 VVKSVA9MS13-1 J AZ FL Display
FW601 QCNWN1249AWZZ J AE Flat Wire,5Pin
FW701 QCNWN1457AWZZ J AD Flat Wire,9Pin
FW703 QCNWN1458AWZZ J AD Flat Wire,10Pin
FW705 QCNWN0713AWZZ J AF Flat Wire,3Pin
FWM1 QCNWN1274AWZZ J AC Flat Wire,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Wire,2Pin
JK601 QJAKM0004AWZZ J AK Jack,Headphones
! L901 RCILZ0008AWZZ J AH Line Filter
M1 92LMTR1854CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LMTR3022AS1 J AU Motor with Worm
[Turntable Up/Down/Loading]
MM1(220-1) RMOTV0006AWM1 J AR Motor with Pulley [Tape]
PHM1 VHPI31535CD-1 J AG Phote Interrupter
! RL901 RRLYD0011AWZZ J AE Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO301 QTANC0101AWZZ J AF Terminal,Antenna
SO601 QTANA0412AWZZ J AF Terminal,Speaker
! SO901 QSOCA0204AWZZ J AF Socket,AC Input
SOLM1 RPLU-0002AWZZ J AH Solenoid Ass’y
SOLM2 RPLU-0002AWZZ J AH Solenoid Ass’y
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
SW701 92LSWICH-1401A J AC Switch,Key Type [On/Stand-by]
SW702 92LSWICH-1401A J AC Switch,Key Type [Clock]
SW703 92LSWICH-1401A J AC Switch,Key Type [Timer/Sleep]
SW707 92LSWICH-1401A J AC Switch,Key Type [Disk Skip]
SW708 92LSWICH-1401A J AC Switch,Key Type [Open/Close]
SW709 92LSWICH-1401A J AC Switch,Key Type [Fast Forward]
SW710 92LSWICH-1401A J AC Switch,Key Type [Record Pause]
SW711 92LSWICH-1401A J AC Switch,Key Type [Memory/Set]
SW712 92LSWICH-1401A J AC Switch,Key Type [Stop]
SW713 92LSWICH-1401A J AC Switch,Key Type [Tuner (BAND)]
SW714 92LSWICH-1401A J AC Switch,Key Type [Tape]
SW715 92LSWICH-1401A J AC Switch,Key Type [CD]
SW716 92LSWICH-1401A J AC Switch,Key Type [Rewind]
SW717 92LSWICH-1401A J AC Switch,Key Type [Tuning Up]
SW718 92LSWICH-1401A J AC Switch,Key Type [Tuning Down]
SW719 92LSWICH-1401A J AC Switch,Key Type [Play]
SW720 92LSWICH-1401A J AC Switch,Key Type [Volume Down]
SW721 92LSWICH-1401A J AC Switch,Key Type [Volume Up]
SW722 92LSWICH-1401A J AC Switch,Key Type
[X-BASS/DEMO]
SWM3(220-8) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4(220-9) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM5(220-10) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
