PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C662
CNP101 92LCONE3P53253 J AB Plug,3Pin
CNP102 92LCONE7P53253 J AC Plug,7Pin
CNP301 92LCONE-3P5268 J AC Plug,3Pin
CNP701 QCNCWZG24AWZZ J AE Socket,24Pin
CNP704 QCNCM705FAFZZ J AB Plug,6Pin
CNP801 QCNCM035CAWZZ J AB Plug,3Pin
CNP802 QCNCM035HAWZZ J AB Plug,8Pin
CNP901 QCNCM010NAWZZ J AC Plug,13Pin
CNP903 92LCONE2P53253 J AB Plug,2Pin
CNPM1 QCNCM932MAFZZ J AE Plug,12Pin
CNPM2 QCNCM030BAWZZ J AB Pin Header,2Pin
CNS1A/B QCNWN1181AWZZ J AK Connector Ass’y,5/5Pin
CNS2A/B QCNWN1182AWZZ J AH Connector Ass’y,8/8Pin
CNS3A/B QCNWN1183AWZZ J AG Connector Ass’y,6/6Pin
CNS101 QCNWN1187AWZZ J AG Socket,3Pin
CNS102 QCNWN1188AWZZ J AM Socket,7Pin
CNS701 QCNCWZF24AWZZ J AE Socket,24Pin
CNS901 QCNCW010NAWZZ J AC Socket,13Pin
CNS903 QCNWN1452AWZZ J AC Socket,2Pin
! F801 QFS-D502CSJNI J AC Fuse,5A/125V
! F804,805 QFS-D502CSJNI J AC Fuse,5A/125V
! F806 QFS-D202DSJNI J AD Fuse,2A/250V
FFC701 QCNWN1453AWZZ J Flat Cable,24Pin
FL701 VVKBJ685GNK-1 J AV FL Display
FW703 QCNWN1427AWZZ J AD Flat Wire,6Pin
FWM1 QCNWN1274AWZZ J AC Flat Cable,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Cable,2Pin
IC99 VHPGP1F32T/-1 J AP Optical Fiber Data Link,
GP1F32T
JK601 QSOCJ0213AWZZ J AE Jack,Video/AUX
JK671 QJAKM0008AWZZ J AF Jack,Headphones
JOG701 QSW-Z0007AWZZ J Switch,Push Type [Volume Jog]
LUG901 QLUGP0001AWZZ J AC Lug Terminal
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LMTR3022AS1 J AU Motor with Worm Pulley
[T/T Up/Down Loading]
M901 92LMTR1810A J AK Motor,Air Cooling Fan
MM1(260-7) RMOTV0006AWM1 J AR Motor with Pulley [Tape]
PHM1 VHPI31535CD-1 J AG Photo Interrupter
PIN103 QLUGP0002AWZZ J AB Lug Pin
RL801 RRLYD0012AWZZ J AM Relay
RL901 RRLYD0004AWZZ J AP Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO901 QTANA0401AWZZ J AG Terminal,Speaker
SOLM1(260-8) RPLU-0002AWZZ J AH Solenoid Ass’y [Tape]
SOLM2 RPLU-0002AWZZ J AH Solenoid Ass’y [CD]
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW701 92LSWICH1401AT J AC Switch,Key Type [POWER]
SW703 92LSWICH1401AT J AC Switch,Key Type [CLOCK]
SW704 92LSWICH1401AT J AC Switch,Key Type
[TIMER/SLEEP]
SW705 92LSWICH1401AT J AC Switch,Key Type [DISC 1]
SW706 92LSWICH1401AT J AC Switch,Key Type [DISC 2]
SW707 92LSWICH1401AT J AC Switch,Key Type [DISC 3]
SW708 92LSWICH1401AT J AC Switch,Key Type [DISC SKIP]
SW709 92LSWICH1401AT J AC Switch,Key Type
[OPEN/CLOSE]
SW710 92LSWICH1401AT J AC Switch,Key Type [REW]
SW711 92LSWICH1401AT J AC Switch,Key Type [REC PAUSE]
SW712 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW713 92LSWICH1401AT J AC Switch,Key Type [STOP]
SW714 92LSWICH1401AT J AC Switch,Key Type
[TUNER (BAND)]
SW715 92LSWICH1401AT J AC Switch,Key Type [VIDEO/AUX]
SW716 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW717 92LSWICH1401AT J AC Switch,Key Type [CD]
SW722 92LSWICH1401AT J AC Switch,Key Type [FF]
SW723 92LSWICH1401AT J AC Switch,Key Type [TUNING UP]
SW724 92LSWICH1401AT J AC Switch,Key Type
[TUNING DOWN]
SW725 92LSWICH1401AT J AC Switch,Key Type [PLAY]
SW728 92LSWICH1401AT J AC Switch,Key Type
[X-BASS/DEMO]
SW729 92LSWICH1401AT J AC Switch,Key Type [EQUALIZER]
SW730 92LSWICH1401AT J AC Switch,Key Type [DIMMER]
SWM3(260-9) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4(260-10) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM5(260-11) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 GCAB-1044AWSA J AM CD Player Base
202 92LCAB3081AS1 J BB Front Panel Ass’y
202- 1 ———— — Front Panel
(Not Replacement Item)
202- 2 JKNBZ0557AWSA J AE Button,Disc No.
202- 3 JKNBZ0558AWSA J AE Button,Open/Close/Disc Skip
202- 4 JKNBZ0559AWSA J AE Button,Power
202- 5 JKNBZ0560AWSA J AE Button,X-BASS/Demo
202- 6 JKNBZ0563AWSA J AG Button,FF/REW/Tuning
202- 7 JKNBZ0622AWSA J AD Button,Timer/Sleep/Clock
202- 8 JKNBZ0621AWSA J AD Button,Dimmer/Equalizer
202-10 KNOB3051AASY1 J AK Button,Function
202-11 HDECQ0412AWSA J AC Operation Ring A
202-12 HDECQ0413AWSA J AF Operation Ring B
202-13 HDECQ0414AWSA J AD Cap,Operation Center
202-14 HDECQ0415AWSA J AD Cover,LED
202-15 HDECQ0417AWSA J AE Panel,Center Cap
202-16 HDECQ0418AWSC J AH Panel,Decoration
202-17 HDECQ0419AWSA J AF Decoration,Play Button
202-18 HDECQ0420AWSA J AE Decoration,Stop Button
202-19 HDECQ0467AWSA J AH Panel,AMP.
202-20 HDECQ0457AWSA J AC Panel,Play Decoration
202-21 HDECQ0458AWSA J AC Panel,Stop Decoration
202-22 PSHEP0031AWZZ J AC Sheet,Reflector
203 92LMEC3051CTS1 J AN Cassette,Holder Ass’y,Tape 1
203- 1 ———— — Cassette Holder,Tape 1
(Not Replacement Item)
203- 2 GCOVA1221AWSB J AH Cassette Cover,Tape 1
203- 3 HDECQ0408AWSA J AD Panel,Cassette,Tape 1
204 92LMEC3051CTS2 J AN Cassette,Holder Ass’y,Tape 2
204- 1 ———— — Cassette Holder,Tape 2
(Not Replacement Item)
204- 2 GCOVA1222AWSB J AH Cassette Cover,Tape 2
204- 3 HDECQ0409AWSA J AD Panel,Cassette,Tape 2
205 92LKNOB3081BS1 J Button,Volume Ass’y
205- 1 ———— — Button,Volume
(Not Replacement Item)
205- 2 92LCSPR1431C J AA Spring,Ring
205- 3 GCOVA1233AWZZ J Refelector B
206 MSPRD0092AWFJ J AB Spring,Cassette,Tape 1
207 MSPRD0093AWFJ J AB Spring,Cassette,Tape 2
208 92LHOLD3022AS1 J AB Stabilizer Ass’y
208- 1 ———— — Stabilizer
(Not Replacement Item)
208- 2 PMAGF0001AWZZ J AF Magnet,Stabilizer
208- 3 92LSUPT1749D J AA Support,Stabilizer Magnet
209 MLEVP0067AWZZ J AC Lever,Lock
210 LCHSZ0011AWZZ J AG Chassis,CD Mechanism
211 LHLDZ1141AWZZ J AB Support,Pitch
212 MLEVP0066AWZZ J AE Lever,Shift
213 MLEVP0068AWZZ J AB Lever,Change
214 MSPRC0024AWFW J AB Spring,Solenoid
215 NBLTK0033AWZZ J AC Belt,Drive
216 NGERH0064AWZZ J AD Gear,Cam
217 NGERH0065AWZZ J AB Gear,Turntable
218 NGERK0003AWZZ J AC Gear,Drive
– 5 –
