NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-DP2500W/DK2500W
RK9~11 VRD-ST2CD102J J AA 1 kohm,1/6W [CD-DK2500W]
RK12 VRD-ST2CD101J J AA 100 ohm,1/6W [CD-DK2500W]
RK13 VRD-ST2CD122J J AA 1.2 kohms,1/6W [CD-DK2500W]
RK14,15 VRD-RT2HD101J J AA 100 ohm,1/2W [CD-DK2500W]
RK36,37 VRD-ST2CD102J J AA 1 kohm,1/6W [CD-DK2500W]
RK38 VRD-ST2CD101J J AA 100 kohm,1/6W [CD-DK2500W]
RK39,40 VRD-ST2CD102J J AA 1 kohm,1/6W [CD-DK2500W]
RK41,42 VRD-ST2CD152J J AA 1.5 kohm,1/6W [CD-DK2500W]
RK43,44 VRD-ST2CD474J J AA 47 kohms,1/6W [CD-DK2500W]
RK45,46 VRD-ST2CD102J J AA 1 kohm,1/6W [CD-DK2500W]
RK47,48 VRD-ST2CD681J J AA 680 kohms,1/6W [CD-DK2500W]
RM710~712 VRD-MN2BD104J J AA 100 kohm,1/8W
RM713~715 VRD-ST2CD102J J AA 1 kohm,1/6W
RS701~704 VRD-ST2CD102J J AA 1 kohm,1/6W
RS705 VRD-ST2CD102J J AA 1 kohm,1/6W
RS708~710 VRD-MN2BD103J J AA 10 kohm,1/8W
RS711,712 VRD-ST2CD102J J AA 1 kohm,1/6W
RS714 VRD-MN2BD102J J AA 1 kohm,1/8W
RS715 VRD-ST2CD102J J AA 1 kohm,1/6W
RS716 VRD-MN2BD102J J AA 1 kohm,1/8W
RS717,718 VRD-ST2CD102J J AA 1 kohm,1/6W
RS720 VRD-MN2BD221J J AA 220 ohms,1/8W
RS721~723 VRD-ST2CD102J J AA 1 kohm,1/6W
RS724~726 VRD-MN2BD103J J AA 10 kohm,1/8W
RS727~732 VRD-ST2CD102J J AA 1 kohm,1/6W
OTHER CIRCUITRY PARTS
BI4/CNS4 QCNWN1572AWZZ J AF Connector Ass’y,6/6Pin
BI99/CNS99 QCNWN1611AWZZ J AG Connector Ass’y,3/3Pin
BI401/CNS401 QCNWN1540AWZZ J AF Connector Ass’y,5/5Pin
BI701/CNS701 QCNWN1541AWZZ J AH Connector Ass’y,10/10Pin
BI702/CNS702 QCNWN1607AWZZ J AG Connector Ass’y,9/9Pin
BIK1/CNSK1 QCNWN1573AWZZ J Connector Ass’y,11/11Pin
[CD-DK2500W]
CNP1 QCNCM704GAWZZ J AC Plug,7Pin
CNP2 QCNCM704HAWZZ J AC Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP4 QCNCM705FAFZZ J AB Plug,6Pin
CNP5 92LCONE3P53254 J AB Plug,3Pin
CNP11 92LCONE5P53254 J AB Plug,5Pin
CNP12 92LCONEAP53254 J AD Plug,10Pin
CNP101 QCNCM705CAFZZ J AA Plug,3Pin
CNP102/CNS102 QCNWN1609AWZZ J AB Connector Ass’y,7/7Pin
CNP301 92LCONE2P5268 J AB Plug,2Pin
CNP401 92LCONEBP53253 J AC Plug,11Pin [CD-DK2500W]
CNP501 QCNCM010NAWZZ J AC Plug,13Pin
CNP601 92LCONE5P52287 J AC Socket,5Pin
CNP602 QCNCWZG23AWZZ J AK Plug,23Pin [CD-DP2500W]
CNP602 QCNCWZG25AWZZ J AE Socket,25Pin [CD-DK2500W]
CNP701 QCNCWZF23AWZZ J AK Plug,23Pin [CD-DP2500W]
CNP701 QCNCWZF25AWZZ J AE Socket,25Pin [CD-DK2500W]
CNP702 QCNCWZF13AWZZ J Plug,13Pin
! CNP801 QCNCM049EAWZZ J AD Plug,9Pin
CNP802 92LCONE8P5267X J AD Plug,8Pin
CNP803 QCNWM050CAWZZ J Plug,3Pin
CNP804 92LCONE9P53253 J AC Plug,9Pin
CNP805 QCNCW010NAWZZ J Socket,13Pin
CNP806 92LCONE2P53253 J AB Plug,2Pin
CNS1A/B QCNWN1537AWZZ J AG Connector Ass’y,7/7Pin
CNS2A/B QCNWN1538AWZZ J AG Connector Ass’y,8/8Pin
CNS3A/B QCNWN1539AWZZ J AE Connector Ass’y,6/6Pin
CNS100 QCNWN1417AWZZ J Lead Wire Ass’y, with Lug
CNS806 QCNWN1542AWZZ J AC Connector Ass’y,2Pin
CNS907 QCNWN1610AWZZ J AD Flat Wire,5Pin
! F801,802 92LFUSET502E J AC Fuse,T5A L 250V
! F803,804 92LFUSET402E J AD Fuse,T4A L 250V
! F805 92LFUSET202E J Fuse,T2A L 250V
FC701 QCNWN1564AWZZ J AG Flat Cable,23Pin [CD-DP2500W]
FC701 QCNWN1568AWZZ J AG Flat Cable,25Pin [CD-DK2500W]
FC702 QCNWN1417AWZZ J Flat Cable,13Pin
FL701 VVKBJ744GNK-1 J BD FL Display
IC99 VHPTOTX178A-1 J AP Optical Fiber Data
Link,TOTX178A
JK1 QJAKJ0007AWZZ J AF Jack,Mic 1 [CD-DK2500W]
JK2 QJAKJ0007AWZZ J AF Jack,Mic 2 [CD-DK2500W]
JK201 QSOCJ0409AWZZ J AF Jack,Video In
JK601 QJAKM0004AWZZ J AK Jack,Headphones
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LTWMEN7E6Y J AR Motor with Worm Pulley
[T/T Up/Down Loading]
M901 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
! RL801 RRLYD0011AWZZ J AQ Relay
RL901,902 RRLYD0014AWZZ J AK Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO301 QTANC0206AWZZ J Terminal,Antenna
SO901 QTANA1003AWZZ J AH Terminal,Speaker
SW1 SWMPU10780MLB J Switch,Push Type [Open/Close]
SW2 SWMPU11470MLB J Switch,Push Type [Clamp]
SW3 SWMPU11470MLB J Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW701 92LSWICH1401AT J AC Switch,Key Type [CD]
SW702 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW703 92LSWICH1401AT J AC Switch,Key Type
[TUNING DOWN]
SW704 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW705 92LSWICH1401AT J AC Switch,Key Type [REV]
SW706 92LSWICH1401AT J AC Switch,Key Type [FF]
SW707 92LSWICH1401AT J AC Switch,Key Type [PLAY]
SW708 92LSWICH1401AT J AC Switch,Key Type [STOP]
SW709 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW710 92LSWICH1401AT J AC Switch,Key Type [REC]
SW711 92LSWICH1401AT J AC Switch,Key Type [TUNING UP]
SW712 92LSWICH1401AT J AC Switch,Key Type [VIDEO]
SW713 92LSWICH1401AT J AC Switch,Key Type [TUNER]
SW714 92LSWICH1401AT J AC Switch,Key Type [DIMMER]
SW715 92LSWICH1401AT J AC Switch,Key Type [X-BASS]
SW716 92LSWICH1401AT J AC Switch,Key Type [EQUAL]
SW717 92LSWICH1401AT J AC Switch,Key Type [NORMAL]
SW718 92LSWICH1401AT J AC Switch,Key Type [PHANTOM]
SW719 92LSWICH1401AT J AC Switch,Key Type [BY-PASS]
SW720 92LSWICH1401AT J AC Switch,Key Type
[ON/STAND-BY]
SW721 92LSWICH1401AT J AC Switch,Key Type [CLOCK]
SW722 92LSWICH1401AT J AC Switch,Key Type [TIMER]
SW728 92LSWICH1401AT J AC Switch,Key Type [DISC 1]
SW729 92LSWICH1401AT J AC Switch,Key Type [DISC 2]
SW730 92LSWICH1401AT J AC Switch,Key Type [DISC 3]
SW731 92LSWICH1401AT J AC Switch,Key Type [DISC SKIP]
SW732 92LSWICH1401AT J AC Switch,Key Type
[OPEN/CLOSE]
SW733 92LSWICH1401AT J AC Switch,Key Type
[Reverse Mode]
SW799 QSW-S0024AWZZ J AE Switch,Slide Type
[SPAN SELECTOR]
! SW801 QSOCE0008AWZZ J AH Switch,Slide Type,Voltage
Selector
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×3.8×0.25mm
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
PSLDM3015AWFW J AD Shield Plate
201 92LCAB3309AASY J Front Panel Ass’y
[CD-DP2500W]
201 92LCAB3310AASY J Front Panel Ass’y
[CD-DK2500W]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 92LBADGE1671A J AC Badg,SHARP
201- 3 GCOVA1251AWSA J AH Cover,Cassette Holder,Tape 1
– 6 –
