Sharp CD-DP2500W User Manual

PRICE
RANK
DESCRIPTIONNO. PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-DP2500W/DK2500W
201- 4 GCOVA1256AWSA J AB Indicator,PRESET
201- 5 GCOVA1258AWSA J AB Indicator,TIMER
201- 6 GCOVA1260AWSA J AB Indicator,Disc 1
201- 7 GCOVA1265AWZZ J AC Indicator,CD
201- 8 GCOVA1266AWZZ J AC Indicator,TUNER
201- 9 GCOVA1267AWZZ J AC Indicator,TAPE
201-10 GCOVA1268AWZZ J AC Indicator,VIDEO/AUX
201-11 GCOVA1275AWSA J AB Indicator,Disc 2
201-12 GCOVA1276AWSA J AB Indicator,Disc 3
201-13 GCOVA1277AWSA J AB Indicator,MULTI OPERATION
201-14 GCOVA1298AWSA J AE Cover,Cassette Holder,Tape 2
201-15 GDORF0074AWSA J AE Holder,Cassette,Tape 1
201-16 GDORF0075AWSA J AE Holder,Cassette,Tape 2
201-17 HDECQ0521AWSA J AD Panel,Cassette Cover,Tape 1
201-18 HDECQ0522AWSA J AD Panel,Cassette Cover,Tape 2
201-19 HDECQ0526AWSA J AE Light Up Ring,VOLUME
201-20 HDECQ0566AWSA J Panel,Center Operation
201-21 HDECQ0580AWSA J Panel Amp. [CD-DK2500W]
201-21 HDECQ0581AWSA J Panel Amp. [CD-DP2500W]
201-22 JKNBZ0660AWSA J AF Button,TUNNING
201-23 JKNBZ0661AWSA J AE Button,DIMMER
201-24 JKNBZ0663AWSA J AE Button,DOLBY/CENTER MODE
201-25 JKNBZ0665AWSA J AF Button,Disc Number
201-26 JKNBZ0672AWSA J AF Button,Function A
201-27 JKNBZ0673AWSA J AF Button,Function B
201-28 JKNBZ0683AWSA J AG BUtton,Center Operation
201-29 JKNBZ0714AWSA J AF Button,ON/STAND-BY
201-30 MLIFP0008AWZZ J AD Damper
201-31 MSPRD0127AWFJ J AB Spring,Cassette Tape 2
201-32 MSPRD0138AWFJ J Spring,Cassette Tape 1
201-33 PSHEM0008AWZZ J Shield Sheet
201-34 PSHEP0042AWZZ J Spacer,Operation Button A
201-35 PSHEP0043AWZZ J Spacer,Operation Button B
202 92LCAB3303BASY J Side Panel Ass’y,Left
202- 1 ———— — Side Panel Ass’y,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3303CASY J Side Panel Ass’y,Right
203- 1 ———— — Side Panel Ass’y,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 COV3303AASY1 J AM CD Tray Cover Ass’y
204- 1 ———— — Cover,CD Tray
(Not Replacement Item)
204- 2 GCOVA1254AWSA J AE Cover,CD Tray,Left
204- 3 GCOVA1255AWSA J AE Cover,CD Tray,Right
205 GCAB-1184AWSA J AP Cabinet,Top
206 GCOVA1264AWZZ J AC Cover,Volume Knob
207 GITAR0592AWSA J Rear Panel [CD-DK2500W]
207 GITAR0593AWSA J Rear Panel [CD-DP2500W]
208 JKNBK0012AWSG J AK Knob,Mic Level [CD-DK2500W]
209 JKNBK0072AWSA J AE Knob,VOLUME
210 KMECB0014AWZZ J Tape Mechanism Ass’y
211 LANGK0110AWFW1J AD Bracket,Casette Lock Lever,
Tape 1
212 LANGK0111AWFW1J AD Bracket,Casette Lock Lever,
Tape 2
213 LANGK0188AWFW J AF Bracket,Fan Motor
214 LANGK0189AWFW J AC Bracket,SUb Heat Sink A
Support
217 LANGK0208AWFW J Bracket,PWB Support
218 LANGT0042AWFW J AC Bracket,PWB Support
219 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
220 LCHSM0096AWFW J AR Chassis,Main
222 LHLDK9001AW00 J AB Band
224 LHLDZ1242AWZZ J AE FL HOLDER
225 LHLDZ1244AWZZ J AE Holder,Dolby LED
226 LHLDZ1245AWZZ J AE Holder,Volume LED
227 LHLDZ1247AWZZ J AE Holder,Function LED
228 LHLDZ1252AWZZ J Holder,Disc Namber LED
229 LHLDZ1253AWZZ J Holder,Operation LED
232 MLOKC0003AWZZ J AD Lock Lever,Casette,Tape 1
233 MLOKC0004AWZZ J AD Lock Lever,Casette,Tape 2
234 MSPRD0109AWFJ J AB
Spring,Casette Lock Lever,Tape 1
235 MSPRD0110AWFJ J AB Spring,Casette Lock Lever,Tape 2
237 NFANP0001AWZZ J AD Rotary,Fan
241 PCUSG0022AWZZ J AB Cushion,Leg
243 PRDAR0149AWFW J AP Heat Sink,Main
244 PRDAR0150AWFW J AS Heat Sink,Sub,B
245 PRDAR0151AWFW J AG Heat Sink,Sub,A
246 PSHEP0037AWZZ J AC Sheet,Reflector
! 247 QACCA0003AW00 J AC Power Supply Cord
[For Saudi Arabia]
! 247 QACCB0006AW00 J AU AC Power Supply Cord
[For Hong Kong]
! 247 QACCE0010AW00 J AK AC Power Supply Cord
[Except for Saudi Arabia/Hong
Kong/Tailand]
! 247 QACCJ0007AW00 J AC Power Supply Cord
[For Tailand]
248 QFSHD0001AWZZ J AB Holder,Fuse
249 QLUGP0001AWZZ J AC Lug (LUG901,902)
250 QLUGP0002AWZZ J AB Lug (LUG101)
251 92LBE241414 J AD Belt
252 92LCAUT1706A1 J AC Caution Lavel,Class 3 Laser
253 92LCAUT1706B J AA Label,Laser
254 92LCSPR1431C J AA Spring,Ring
255 92LEVA0330702 J AD Velvet Carpet,Cushion
! 256 92LLUG1746A J AA Lug (K801,802)
257 92LMAG0104302 J AE Magnet
258 92LMT0304302 J AB Plate,Metal
259 92LNBAND1318A J AA Nylon Band
260 92LNM0305401 J AB Velvet Carpet
261 92LPT0303002 J AB Roller
262 92LPT0304303 J AB Lever,Stop
263 92LPT0304304 J AB Stopper
264 92LPT0304305 J AE Lever,Lock
265 92LPT0304306 J AG Stabilizer
266 92LPT0304307 J AC Support,Cam
267 92LPT0304308 J AB Lock Gear Pin
268 92LPT0304309 J AB Cap,Pulley Stopper
269 92LPT0305413 J AG Cam Gear Lower
270 92LPT0309506 J AD Gear,Turntable Drive
271 92LPT0309507 J AD Gear,Open/Close Drive
272 92LPT0309508 J AD Gear,Planet
273 92LPT0309509 J AD Gear,Drive
274 92LPT0309510 J AE Gear,Pulley
275 92LPT0309511 J AD Gear,Middle
276 92LPT0311101 J AB Lever,Clamp
277 92LPT0311102 J AC Lever,Disc
278 92LPT0312005 J AL Gear,Cam
279 92LPT0320201 J AE Support,Stabilizer
280 92LPT0330301 J AU Chassie
281 92LPT0330803 J AK CD,Chassis
282 92LPT0331003 J AT Holder,Slide
283 92LPT0331105 J AM Turntable
284 92LSP0304303 J AB Spring,Stopper
285 92LSP0304305 J AB Spring,Lock Lever
286 92LSP0304306 J AG Spring,Lock Gear
287 TSPC-0706AWZZ J Label,Specification
[CD-DP2500W for Central &
South America/Mexico]
287 TSPC-0707AWZZ J Label,Specification
[CD-DP2500W for Taiwan]
287 TSPC-0708AWZZ J Label,Specification
[CD-DP2500W for Thailand]
287 TSPC-0710AWZZ J Label,Specification
[CD-DK2500W for Taiwan]
287 TSPC-0711AWZZ J Label,Specification
[CD-DK2500W for Thailand]
601 XBBSD20P04000 J AA Screw,ø2×4mm
604 XEBSF30P12000 J AA Screw,ø3×12mm
605 XESSD30P10000 J AA Screw,ø3×10mm
606 XHBSD26P04000 J AA Screw,ø2.6×4mm
607 XHBSD30P06000 J AA Screw,ø3×6mm
608 XJBSD30P10000 J AA Screw,ø3×10mm
609 XJBSD30P14000 J AA Screw,ø3×14mm
611 XJSSD30P10000 J AA Screw,ø3×10mm
612 LX-BZ2222AXZZ J Screw,Special
613 LX-HZ0082AFZZ J AA Screw,ø4×8mm
614 LX-JZ0010AFFD J AA Screw,ø3×10mm
616 92LSC0308RBZZ J Screw,ø3×8mm
FRONT SPEAKER
901 92LJ1924A J AN Front Panel
903 92LJ1925A J AU Net Frame Ass’y
905 92L9547C-1 J Speaker Box Ass’y
907 92LP5876-2 J AC Label,Specification
909 92LJ9774A J AC Cushion,Foot
910 92LJ9777P J AD Port Cushion
912 92LJ9802 J AF Catching Holder
913 92LF1228A J AC Screw,ø4×12mm
– 7 –
