CD-E700H
General Information
! Display
1. CD Pause Indicator
2. Extra Bass Indicator
3. Disc Number Indicators
4.Tape 2 Record Indicator
5.FM Stereo Mode Indicator
6.FM Stereo Receiving Indicator
7.Timer Play Indicator
8.Sleep Indicator
9.Timer Recording Indicator
10. CD Play Indicator
11. CD Repeat Play Indicator
12. RDS Indicator
13. Dynamic PTY Indicator
14.Tape Play Indicator
15. Traffic Programme Indicator
16. Traffic Announcement Indicator
17.Memory Indicator
! Rear panel
Reference page
1. Cooling Fan
2.AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
3. FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5. Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . 28
6.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
Note:
This product is equipped with a cooling fan inside, which begins to
run at a specified volume level for better heat radiation.
! Speaker system
1. Super Tweeters
2. Woofer
3. Tweeter
4. Passive Radiator
5. Speaker Wire
1
4
3
5
2
2
1
5
6
4
3
14 17
23456791 8
12
10
11
13
15 16
