02/12/6 CD-E700H(H)E3.fm
E-32
ENGLISH
8
CD-E700H
References
! CD player
! Tuner
! Cassette deck
! Speaker
Type 3-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.35 % (DIN 45 511)
Type 3-way 4-speaker system with passive radia-
tor
Super tweeter 2
5 cm (2") tweeter
16 cm (6-1/2") woofer
16 cm (6-1/2") passive radiator
Maximum input
power
250 W
Rated input power 125 W
Impedance 6 ohms
Dimensions Width: 277 mm (10-7/8")
Height: 330 mm (13")
Depth: 273 mm (10-3/4")
Weight 4.5 kg (9.9 lbs.)/each
