Sharp CD-G15000 - Page 47

47
06/1/5
References
CD-G15000_E3.fm
TINSEA128AWZZ
CP-G15000
CD-G15000
 Tuner
 Cassette deck
 Front speaker
 Rear speaker
 Active subwoofer
Frequency range FM: 87.5 - 108.0 MHz
AM: 530 - 1,720 kHz
Frequency response 50 - 14,000 Hz (normal tape)
Signal/noise ratio 55 dB (TAPE-1 playback)
50 dB (TAPE-2 recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 2-way type speaker system
2" (5 cm) tweeter x 1
5-1/8" (13 cm) woofer x 2
Maximum input
power
300 W
Rated input power 150 W
Impedance 8 ohms
Dimensions Width: 7-11/16" (195 mm)
Height: 15-3/4" (400 mm)
Depth: 9-5/8" (244 mm)
Weight 4.9 kg (10.8 lbs.)/each
Type Full-range speaker system
4" (10 cm) speaker x 2
Maximum input
power
150 W
Rated input power 75 W
Impedance 16 ohms
Dimensions Width: 5-11/16" (145 mm)
Height: 15-3/4" (400 mm)
Depth: 9-1/8" (231 mm)
Weight 2.9 kg (6.4 lbs.)/each
Power source AC 120 V, 60 Hz
Power
consumption
120 W
Output power 400 watts minimum RMS into 6 ohms from
50 Hz to 120 Hz, 10% total harmonic
distortion
Input terminals Subwoofer input (audio signal):
200mV / 10 k ohms at 70 Hz
Speaker type 10" (25 cm) woofer
Impedance 6 ohms
Dimensions Width: 18-1/8" (460 mm)
Height: 15-3/4" (400 mm)
Depth: 15-13/16" (402 mm)
Weight 21 kg (46.2 lbs.)
