Sharp CD-M4000 Service Manual

CD-M4000W/CP-M4000
AC POWER SUPPLY CORD AND AC PLUG ADAPTOR
QACCA0003AWOO
BzjggK 1
QACCE0008AWOO
QACCL0005AWOO
a -
G-Dj
0
I
I
1 K=
QPLGA0003AWZZ
QPLGA0004AWZZ
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
SPECIFICATIONS
n Amplifier
MPO: 520 W (260 W + 260 W) (10 % T.H.D.)
RMS: 300 W (150 W + 150 W) (10 % T.H.D.)
Video/Auxiliary (audio signal): 500 mV/47 kohms
n CD player
n Tuner
Frequency range
FM: 88 - 108 MHz
AM: 531 1,602 kHz
w Cassette deck
Frequency response
50 14,000 Hz (Normal tape)
Signal/noise ratio / 55 dB (TAPE 1, Dlavbackl
150 dB (TAPE 2, &&din&playback)
Wow and flutter
IO.3 % IWRMS1
TYPO
4-way type speaker system
Super Tweeter
8 cm (3-118”) Tweeter
8 cm (3-118”) Midrange
25 cm (lo”) Woofer
Maximum input power
300 W
(Total)
Rated input power
150w
(Total)
Impedance
6 ohms
Dimensions
Width: 422 mm (16-518”)
Height’ 330 mm (13”)
Depth: 306 mm (12-1116”)
Weight
8.5 kg (18.7 Ibs.)/each
Specifications for this model are subject to change without
prior notice.
