Sharp CD-M4000 User Manual

E-44
CD-M4000V(X)E5.fm01/6/12
ENGLISH
CD-M4000V
References
- Specifications -
Specifications
As part of our policy of continuous improvement, SHARP reserves the right to make
design and specification changes for product improvement without prior notice. The
performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
„
General
„
Amplifier
„
Video CD
„
CD player
„
Tuner
„
Cassette deck
„
Speaker
Power source
AC 110/127/220/230 - 240 V, 50/60 Hz
Power consumption
120 W
Dimensions
Width: 270 mm (10-5/8")
Height: 330 mm (13")
Depth: 372 mm (14-11/16")
Weight
9.4 kg (20.7 lbs.)
Output power
MPO: 520 W (260 W + 260 W) (10 % T.H.D.)
RMS: 300 W (150 W + 150 W) (10 % T.H.D.)
RMS: 244 W (122 W + 122 W) (0.9 % T.H.D.)
Output terminals
Speakers: 6 ohms
Headphones: 16 - 50 ohms (recommended: 32 ohms)
Video out: 1 Vp-p (75 ohms)
Input terminals
Video/Auxiliary (audio signal): 500 mV/47 kohms
Microphone: 1 mV/600 ohms
Video output format
PAL/NTSC
Type
3-disc multi-play compact disc player
Signal readout
Non-contact, 3-beam semiconductor laser pickup
D/A converter
1-bit D/A converter
Frequency response
20 - 20,000 Hz
Dynamic range
90 dB (1 kHz)
Frequency range
FM: 88 - 108 MHz
AM: 531 - 1,602 kHz
Frequency response
50 - 14,000 Hz (Normal tape)
Signal/noise ratio
55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter
0.3 % (WRMS)
Type
4-way type speaker system
Super Tweeter
8 cm (3-1/8") Tweeter
8 cm (3-1/8") Midrange
25 cm (10") Woofer
Maximum input power
(Total)
300 W
Rated input power
(Total)
150 W
Impedance
6 ohms
Dimensions
Width: 422 mm (16-5/8" )
Height: 330 mm (13")
Depth: 374 mm (14-3/4")
Weight
8.5 kg (18.7 lbs.)/each
