E-42
ENGLISH
8
CD-MPX880H
References
Specifications
As part of our policy of continuous improvement, SHARP reserves
the right to make design and specification changes for product
improvement without prior notice. The performance specification
figures indicated are nominal values of production units. There may
be some deviations from these values in individual units.
General
(*) This power consumption value is obtained when the
demonstration mode is cancelled in the power stand-by mode.
Refer to page 8 to cancel the demonstration mode.
Amplifier
Tuner
CD player
Cassette deck
Speaker
Power source AC 220 - 240 V ~ 50 Hz
Power consumption
Power on: 82 W
Power stand-by: 0.6 W (*)
Dimensions Width: 260 mm (10 - 1/4" )
Height: 332 mm (13" )
Depth: 324 mm (12 - 7/8")
Weight 7.4 kg (16.31 lbs.)
Output power PMPO: 880 W
MPO: 440 W (220 W + 220 W) (10 % T.H.D.)
RMS: 280 W (140 W + 140 W) (10 % T.H.D.)
RMS: 200 W (100 W + 100 W) (1 % T.H.D.)
Output terminals Front Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Input terminals Audio In (audio signal):
250 mV/47 k ohms
Frequency range FM: 87.5 - 108.0 MHz
AM: 522 - 1,620 kHz
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.35 % (DIN 45 511)
Type 2-way type speaker system
5 cm (2") tweeter
16 cm (6-5/16") woofer
Maximum input
power
280 W
Rated input power 140 W
Impedance 6 ohms
Dimensions Width: 200 mm (7-7/8")
Height: 330 mm (13")
Depth: 220.5 mm (8 - 11/16")
Weight 3.18 kg (7.0 lbs.)/each
To Next Page
