Sharp CD-PC3500 - Page 64

CD-PC3500
– 10 –
A
B
C
D
E
F
G
H
1
23456
Figure 11 SPEAKER EXPLODED VIEW (1/2)
– 11 –
CP-C3500
903
912x2
912x4
SP3,4
914x2
SP5,6
913x4
910
910
916
909x4
(with
Capacitor C1,2)
C1,2
Capacitor
907
914x2
917
SP1,2
901
905
SUPER
TWEETER
SP1(L-CH)
SP2(R-CH)
TWEETER
SP3(L-CH)
SP4(R-CH)
WOOFER
SP5(L-CH)
SP6(R-CH)
SUPER
TWEETER
SP1(L-CH)
SP2(R-CH)
TWEETER
SP3(L-CH)
SP4(R-CH)
WOOFER
SP5(L-CH)
SP6(R-CH)
C1,2
Capacitor
2.2 µF,100V,
Electrolytic (N.P.)
BK
YE
BK
BK
RED
RED
