Sharp CD-SW300 - Preparation for Use; System Connections

03/12/17 CD-SW300 02-14.fm
11
CD-SW300
Preparation for Use
System connections
AC INPUT
Left speaker Subwoofer
Right speaker
Speaker connection
(see page 12)
Antenna connection (see page 12)
AC power connection (see page 13)
AC Outlet
(AC 120 V, 60 Hz)
Make sure to unplug the AC power cord before any connections.
FM antenna
AM loop antenna
Subwoofer
Light-up wire
Speaker light-up wire Speaker light-up wire
