– 47 –
CD-XP200W
IC701 RH-iX0532AWZZ: System Microcomputer (IX0532AW) (2/2)
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
Port Name Terminal NamePin No. Input/Output
Function
54 P120 O/C SW Input CD OPEN/CLOSE SW.
55 P117 MIC SW Input Mic switch input.
56 P116 KARA_LATCH Output Karaoke latch.
57* P115 NO USE Output Open
58* P114 MPEG POWER Output MPEG power control.
59* P113 RDS RST Output RDS RAM reset.
60* P112 RDS RDDA Input RDS data input.
61* P111 RDS RDCL Output RDS clock.
62* P110 RDS READY Input RDS ready.
63* P107 ILU_LED1 Output Illumination LED1.
64* P106 ILU_LED2 Output Illumination LED2.
65* P105 ILU_LED3 Output Illumination LED3.
66* P104 FOR PLY_LED Output Forward play LED.
67* P103 PEV PLY_LED Output Reverse play LED.
68* P102 STOP_LED Output Stop LED.
69 FIP30 DIST Input Destination input.
70 FIP29 S21 Output FL segment driver.
71-74 P97-P94 S20-S17/DIST3-0 Output Destination output./FL segment driver.
75-78 FIP24-FIP21 S16-S13 Output FL segment driver.
79 VLOAD VLOAD Input FL driver power supp. -30 V
80-91 FIP20-FIP9 S12-S1 Output FL segment driver.
92-100 FIP8-FIP0 G9-G1 Output FL grid driver.
To Next Page
