Sharp CD-XP200W Service Manual

PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-XP200W
SW716 92LSWICH1401AT J AC Switch,Key Type
[Tuning/Time Up]
SW717 92LSWICH1401AT J AC Switch,Key Type [Rec Pause]
SW718 92LSWICH1401AT J AC Switch,Key Type [Memory/Set]
SW719 92LSWICH1401AT J AC Switch,Key Type
[Tuning/Time Down]
SW720 92LSWICH1401AT J AC Switch,Key Type [Clock]
SW721 92LSWICH1401AT J AC Switch,Key Type [Volume Up]
SW722 92LSWICH1401AT J AC Switch,Key Type [Volume Down]
SW723 92LSWICH1401AT J AC Switch,Key Type [Disc Skip]
SW724 92LSWICH1401AT J AC Switch,Key Type [Open/Close]
SW725 92LSWICH1401AT J AC Switch,Key Type
[Equalizer/X-Bass/Demo]
1 SW801 QSOCE0009AWZZ J AH Switch,Rotary Type
[Voltage Selector]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
1 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×3.8×0.25mm
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 92LCAB4239AASY J Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 GCOVA1417AWSA J AH Cover,Cassette [Tape 1]
201- 3 GCOVA1418AWSA J AH Cover,Cassette [Tape 2]
201- 4 GCOVA1421AWSA J AC Cover,Remote Sensor
201- 5 GCOVA1422AWSA J AB Cover,LED,Timer
201- 6 GDORF0112AWSA J AE Holder,Cassette [Tape 1]
201- 7 GDORF0113AWSA J AE Holder,Cassette [Tape 2]
201- 8 HDECQ0834AWSA J AE Panel,Cassette [Tape 1]
201- 9 HDECQ0835AWSA J AE Panel,Cassette [Tape 2]
201-10 HDECQ0919AWSA J Panel,Amp.
201-11 HDECQ0844AWSA J AC Ring,Play/Stop
201-12 HDECQ0850AWSA J AH Panel,FL Display
201-13 JKNBZ0862AWSA J AH Button,Volume
201-14 JKNBZ0890AWSA J AH Button,Operation
201-15 JKNBZ0864AWSA J AC Button,X-Bass/Equalizer
201-16 JKNBZ0865AWSA J AD Button,Function
201-17 JKNBZ0884AWSA J AE Button,On/Stand-by
201-18 LHLDZ1424AWZZ J AF Block,Button
201-19 MLIFP0008AWZZ J AD Damper
201-20 MSPRD0151AWFJ J AB Spring,Cassette [Tape 1]
201-21 MSPRD0152AWFJ J AB Spring,Cassette [Tape 2]
202 92LCAB3838BASY J AN Side Panel Ass’y,Left
202- 1 ———— — Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3838CASY J AN Side Panel Ass’y,Right
203- 1 ———— — Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 GCAB-1197AWZZ J AM Loading Tray
205 GCAB-1215AWSA J AT Top Cabinet
206 GCOVA1416AWSA J AL Cover,CD Tray
207 GITAR1057AWSA J Rear Panel
208 KMECB0025AWZZ J BG Tape Mechanism Ass’y
208- 1 92PF513-853 J BL Head Plate Block [Tape 2]
208- 2 92PF525-336 J BE Motor with Pulley [Tape]
208- 3 92PF567-677 J — Tape Mechanism PWB Ass’y
208- 4 92PFF19N-21 J AL Belt,Main [Tape 2]
208- 5 92PF514-133 J AL Pinch Roller
208- 6 92PF19S-31 J AL Belt,FF/REW [Tape 2]
208- 7 92PFF19N-11 J AL Belt,Main [Tape 1]
208- 8 92PF522-061 J AZ Clutch Ass’y Block [Tape 1]
208- 9 92PFF19S-52 J AL Belt,FF/REW [Tape 1]
208-10 92PF513-861 J AG Head Plate Block [Tape 1]
208-11 92PF522-063 J AZ Clutch Ass’y Block [Tape 2]
208-12 92PFD60F-11 J AK Cam Gear [Tape 1]
208-13 92PFR26C-11 J AN Flywheel [Tape 1]
208-14 92PFR26D-11 J AN Flywheel [Tape 2]
208-15 92PF765-292 J AS Solenoid Ass’y
208-16 92PFD58M-14 J AK Cam Gear [Tape 2]
209 LANGK0110AWFW J AE Bracket,Cassette Lock,Tape 1
210 LANGK0111AWFW J AE Bracket,Cassette Lock,Tape 2
211 LANGK0300AWFW J AE Bracket,Fan Support
212 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
213 LCHSM0157AWFW J AP Chassis,Main
214 LCHSM0155AWZZ J AS Chassis,Loading
215 LHLDM1018AWZZ J AE Stabilizer
216 LHLDZ1357AWZZ J AH Holder,CD Mechanism
217 LHLDZ1358AWZZ J AF Holder,Stabilizer
218 LHLDZ1359AWZZ J AD Holder,Gear
219 LHLDZ1410AWZZ J AD Holder,FL Display
220 LHLDZ1412AWZZ J AC Holder,LED
221 MCAMP0010AWZZ J AE Gear,Cam Upper
222 MCAMP0011AWZZ J AE Gear,Cam Lower
223 MLEVP0109AWZZ J AB Lever,Cam Lock
224 MLEVP0110AWZZ J AB Lever,Switch A
225 MLEVP0111AWZZ J AB Lever,Switch B
226 MLEVP0112AWZZ J AB Turntable Actuator
227 MLOKC0003AWZZ J AD Lock Lever,Cassette,Tape 1
228 MLOKC0004AWZZ J AD Lock Lever,Cassette,Tape 2
229 MSPRC0033AWFJ J AB Spring,Friction
230 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
231 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
232 MSPRP0057AWFW J AC Spring,Tray Lock
233 MSPRP0068AWFW J AB Spring,Motor Gear
234 NFANP0001AWZZ J AD Rotary Fan
235 NGERH0152AWZZ J AC Gear,Turntable Drive
236 NGERH0153AWZZ J AC Gear,Drive
237 NGERW0020AWZZ J AC Gear,Center
238 NGERW0021AWZZ J AC Gear,Idler
239 NGERW0022AWZZ J AD Gear,Worm
240 NGERW0023AWZZ J AC Gear,Motor
241 NTNT-0022AWZZ J AK Turntable
242 PCUSG0022AWZZ J AB Cushion,Leg
243 PMAGF0001AWZZ J AF Magnet
244 PRDAR0244AWFW J Heat Sink,Main
1 245 QACCA0003AW00 J AL AC Power Supply Cord
1 245 QACCE0012AW00 J AH AC Power Supply Cord
1 245 QACCL0005AW00 J AN AC Power Supply Cord
1 245 QACCZ0007AW00 J AP AC Power Supply Cord
246 QCNWN1860AWZZ J AC Lug Wire
1 247 QFSHD0001AWZZ J AB Holder,Fuse
248 92LCSPR1431C J AA Spring,Ring
249 92LMT0304302 J AB Plate,Metal
250 92LNBAND1318A J AA Nylon Band,80mm
251 92LPT0303002 J AB Roller
252 LANGK0326AWFW J AD Bracket,PWB
253 PRDAR0199AWFW J AH Heat Sink,Sub
254 TLABS0354AWZZ J AC Label,Class 3A
255 JKNBK0012AWSK J AK Knob,Mic
256 QCNWN2030AWZZ J AD Lug Wire
257 PSLDM9004AWFW J Shield Plate,Power Transformer
258 PSHEZ0178AWZZ J Sheet,Power Transformer
601 LX-BZ0082AWFC J AE Screw,Transport
602 LX-EZ0010AWFD J AA Screw,Special
603 LX-HZ0009AWFD J AC Screw,ø2×13mm
604 LX-JZ0010AFFD J AA Screw,ø3×10mm
605 XBBSD20P04000 J AA Screw,ø2×4mm
606 XEBSD26P08000 J AA Screw,ø2.6×8mm
607 XEBSD30P08000 J AA Screw,ø3×8mm
608 XEBSD30P10000 J AA Screw,ø3×10mm
609 XEBSD30P12000 J AA Screw,ø3×12mm
610 XESSD30P10000 J AA Screw,ø3×10mm
611 XHBSD26P04000 J AA Screw,ø2.6×4mm
612 XHBSD40P08000 J AA Screw,ø4×8mm
613 XJBSD20P05000 J AA Screw,ø2×5mm
614 XJBSD30P10000 J AA Screw,ø3×10mm
615 XJBSD30P06000 J AA Screw,ø3×6mm
616 XJBSD30P14000 J AA Screw,ø3×14mm
617 XJBSF30P10000 J AA Screw,ø3×10mm
618 XJSSD30P10000 J AA Screw,ø3×10mm
619 92LSC0310RBZI J AB Screw,ø3×10mm
620 92LSC0314WBZI J AB Screw,ø3×14mm
621 LX-JZ0036AWFD J AB Screw,Special
