CD-XP500/CD-XP5500
– 12 –
Figure 12-1
Figure 12-2
1 Woofer 1. Front Panel ............. (A1) x1 12-1
2. Screw ...................... (A2) x8 12-2
2 Tweeter 1. Screw ...................... (B1) x2 12-2
STEP
REMOVAL
PROCEDURE
FIGURE
CP-XP500/CP-XP5500
Screwdriver
Driver should
be pried away
from Speaker Box.
Speaker Box
(A1)x1
(A2)x4
ø4x12mm
(A2)x4
ø4x12mm
(B1)x2
ø3x10mm
Speaker Box
Woofer
Woofer
Tweeter
