Sharp CD-XP7700

PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-XP700/CD-XP7700
CD-XP700/CD-XP7700
INTEGRATED CIRCUITS
IC1 VHILC78645NE1 J AY CD Servo,LC78645NE
IC2 VHIM63001FP-1 J AX Focus/Tracking/Spin/Sled
Driver,M63001FP
IC3 VHILC78683E-1 J BH MP3 Decoder,LC78683E
IC4 VHILC32V4265B1 J 4M DRAM,LC32V4265B
IC5 RH-IX0505AW00 J CD Signal Control,IX0505AW
IC6 VHISI3033LU-1 J AG Voltage Regulator,SI3033LU
IC7 VHISI3033LUS1 J AG Voltage Regulator,SI3033LUS
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC601 VHILC75341/-1 J AM Audio Processor,LC75341
IC701 RH-IX0499AWZZ J AM System Microcomputer,
IX0499AW
IC851 VHIKIA7812AP1 J AF Voltage Regulator,KIA7812AP
IC852 VHIKIA7810AP1 J AF Voltage Regulator,KIA7810AP
IC853 VHIKIA7805AP1 J AF Voltage Regulator,KIA7805AP
IC854 VHIAN78L05/-1 J AE Voltage Regulator,AN78L05
IC855 VSKTC2026//-1 J AF Silicon,NPN,KTC2026
IC901 VHISTK41221-1 J BE Power Amp.,STK41221
TRANSISTORS
Q1 VSKTA1504GR-1 J AB Silicon,PNP,KTA1504 GR
Q2 VSUN2211///-1 J AC Digital,NPN,UN2211
Q3~5 VS2SD601AR/-1 J AC Silicon,NPN,2SD601 AR
Q101~104 VS2SC1845F/-1 J AC Silicon,NPN,2SC1845 F
Q105~108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q111 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q112 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q113,114 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q302 VSKTC3194Y/-1 J AD Silicon,NPN,KTC3194 Y
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q601,602 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q603,604 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q705 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q706~708 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q709,710 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q801 VSKTA1274Y/-1 J AE Silicon,PNP,KTA1274 Y
Q901~905 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q906 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
DIODES
D1,2 VHDKDS193//-1 J AC Silicon,KDS193
D301,302 VHDDS1SS133-1 J AB Silicon,DS1SS133
D305 VHDDS1SS133-1 J AB Silicon,DS1SS133
D703 VHDDS1SS133-1 J AB Silicon,DS1SS133
D709~715 VHDDS1SS133-1 J AB Silicon,DS1SS133
D801 VHDD5SBA60F-1 J AH Silicon,D5SBA60F
D802 VHDD3SBA60F-1 J AG Silicon,D3SBA60F
D803~806 VHDDS1N404S-1 J AB Silicon,DS1N404S
D851,852 VHDDS1SS133-1 J AB Silicon,DS1SS133
D856~859 VHDDS1SS133-1 J AB Silicon,DS1SS133
D905~907 VHDDS1SS133-1 J AB Silicon,DS1SS133
D909,910 VHDDS1N404S-1 J AB Silicon,DS1N404S
D911,912 VHDDS1SS133-1 J AB Silicon,DS1SS133
LED701 VHPSLR342VCJ1 J AC LED,Red,SLR342VCJ
LED703,704 VHPA503BC2E-1 J LED,White,A503BC2E
ZD1 VHEMA8033//-1 J Zener,3.3V,MA8033
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD801,802 VHEDZ6R2BSA-1 J AB Zener,6.2V,DZ6.2BSA
ZD803 VHEDZ300BSB-1 J AB Zener,30V,DZ30BSB
ZD852 VHEDZ8R2BSB-1 J AB Zener,8.2V,DZ8.2BSB
ZD902,903 VHEDZ150BSB-1 J AB Zener,15V,DZ15BSB
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF303 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
1 PT801 RTRNP0437AWZZ J Power
T301 RCILB0065AWZZ J AC FM OSC.
T302 RCILI0017AWZZ J AB FM IF
T303 RCILA0052AWZZ J AE AM Antenna
T306 RCILB0067AWZZ J AD AM OSC.
T351 RCILI0019AWZZ J AD AM IF
COILS
L1 RCILC0011AWZZ J AD 0.82 µH
L2,3 RCILC0012AWZZ J AD 2.2 µH
L103 VP-MK331K0000 J AB 330 µH,Choke
L312 RCILR0056AWZZ J AB FM RF
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L701 VP-DH101K0000 J AB 100 µH,Choke
L901,902 RCILZ0137AFZZ J AA 0.29 µH
VARIABLE CAPACITORS
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCSVC211C/-1 J AG Variable Capacitanse,SVC211C
VIBRATORS
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0015AWZZ J AF Crystal,4.5 MHz
XL1 RCRM-0041AWZZ J AF Ceramic,33.8688 MHz
XL2 RCRM-0043AWZZ J AB Ceramic,4.19 MHz
XL700 RCRSP0003AWZZ J AH Crystal,4.194304 MHz
CAPACITORS
C1 RC-EZY476AF1E J AB 47 µF,25V,Electrolytic
C2 VCKYCY1CB103K J AA 0.01 µF,16V
C3 RC-EZY476AF1E J AB 47 µF,25V,Electrolytic
C4 VCKYCY1HB102K J AA 0.001 µF,50V
C5 VCKYCY1HB473K J AB 0.047 µF,50V
C6 VCKYCY1CB104K J AB 0.1 µF,16V
C8 VCKYCY1HB272K J AA 0.0027 µF,50V
C9 VCCCCY1HH220J J AA 22 pF (CH),50V
C10 RC-EZY107AF1A J AB 100 µF,10V,Electrolytic
C11 RC-EZ0004AWZZ J AD 3.3 µF,16V,Electrolytic
C12 RC-EZY224AF1H J AB 0.22 µF,50V,Electrolytic
C13 VCCCCY1HH101J J AA 100 pF (CH),50V
C14 VCKYCY1EF223Z J AB 0.022 µF,25V
C15,16 VCKYCY1HB102K J AA 0.001 µF,50V
C17 VCKYCY1EF223Z J AB 0.022 µF,25V
C18 RC-EZY107AF1A J AB 100 µF,10V,Electrolytic
C19 VCKYCY1HB102K J AA 0.001 µF,50V
C20 RC-EZY337AF0J J AA 330 µF,6.3V,Electrolytic
C21,22 RC-EZY106AF1E J AB 10 µF,25V,Electrolytic
C23,24 VCKYCY1HB152K J AA 0.0015 µF,50V
C25 VCKYCY1CB103K J AA 0.01 µF,16V
C26 VCKYCY1EF223Z J AB 0.022 µF,25V
C27,28 VCCCCY1HH101J J AA 100 pF (CH),50V
C30~32 VCCCCY1HH101J J AA 100 pF (CH),50V
C33 VCKYCY1HB473K J AB 0.047 µF,50V
C34 RC-EZY224AF1H J AB 0.22 µF,50V,Electrolytic
C35 VCKYCY1CB104K J AB 0.1 µF,16V
C36 VCKYCY1CB103K J AA 0.01 µF,16V
C37 RC-EZY476AF1A J AB 47 µF,10V,Electrolytic
C38 VCKYCY1EF223Z J AB 0.022 µF,25V
C39 VCKYCY1CB104K J AB 0.1 µF,16V
C41 RC-EZY107AF0J J AB 100 µF,6.3V,Electrolytic
C42 RC-EZY227AF1A J AB 220 µF,10V,Electrolytic
C43,44 RC-EZY107AF1A J AB 100 µF,10V,Electrolytic
C50 RC-EZY476AF1A J AB 47 µF,10V,Electrolytic
C51 VCKYCY1CB103K J AA 0.01 µF,16V
C52 VCKYCY1CB104K J AB 0.1 µF,16V
C53 VCKYCY1CB103K J AA 0.01 µF,16V
C60 VCKYCY1CB103K J AA 0.01 µF,16V
C61 VCCCCY1HH330J J AA 33 pF (CH),50V
C62 RC-EZY107AF1A J AB 100 µF,10V,Electrolytic
C63 RC-EZY105AF1H J AB 1 µF,50V,Electrolytic
C64 VCCCCY1HH330J J AA 33 pF (CH),50V
– 1 –
