– 3 –
CD-C622/C2900
Compact disc player section
Type: 3-disc multi-play compact disc
player
Signal readout: Non-contact, 3-beam semi-
conductor laser pickup
D/A Converter: 1-bit D/A converter
Frequency response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz)
Front speaker section
Type: 2-way type [5-1/4" (13 cm)
woofer and super tweeter]
Maximum input power: 60 W
Rated input power: 30 W
Impedance: 6 ohms
Dimensions: Width; 8-11/16" (220 mm)
Height; 11-13/16" (300 mm)
Depth; 8-9/16" (217 mm)
Weight: 5.7 lbs. (2.6 kg)/each
Type: 3-way type [5" (13 cm) woofer,
2" (5 cm) tweeter and super
tweeter]
Maximum input power: 100 W
Rated input power: 50 W
Impedance: 6 ohms
Dimensions: Width; 7-7/8" (200 mm)
Height; 11-13/16" (300 mm)
Depth; 10" (256 mm)
Weight: 6.4 lbs. (2.9 kg)/each
Rear speaker section (CD-C622 Only)
Type: 4" (10 cm) full range speaker
Maximum input power: 20 W
Rated input power: 10 W
Impedance: 16 ohms
Dimensions: Width; 6-3/4" (170 mm)
Height; 6-3/4" (170 mm)
Depth; 3-1/2" (88 mm)
Weight: 0.9 lbs. (0.4 kg)/each
CP-C622
CP-C2900
GBOXS0021AWM1
General
Power source: AC 120 V, 60 Hz
Power consumption: Stand-by; 0.3 W
(CD-C622) Power on; 95 W
Power consumption: Stand-by; 0.3 W
(CD-C2900) Power on; 100 W
Dimensions: Width; 10-5/8" (270 mm)
Height; 11-13/16" (300 mm)
Depth; 13-13/16" (351 mm)
Weight: 13.7 lbs. (6.2 kg)
Amplifier section
Output power: 40 watts minimum RMS per
(CD-C622 Except for channel into 4 ohms from 60 Hz
Canada) to 20 kHz, 10 % total harmonic
distortion
Output power: Front speakers;
(CD-C622 For Canada) MPO; 108 W (54 W + 54 W)
(10 % T.H.D.)
RMS; 60 W (30 W + 30 W)
(10 % T.H.D.)
Rear speakers;
MPO; 36 W (18 W + 18 W)
(10 % T.H.D.)
RMS; 20 W (10 W + 10 W)
(10 % T.H.D.)
Output power: 50 watts minimum RMS per
(CD-C2900 Except for channel into 6 ohms from 60 Hz
Canada) to 20 kHz, 10 % total harmonic
distortion
Output power: MPO; 180 W (90 W + 90 W)
(CD-C2900 For Canada) (10 % T.H.D.)
RMS; 100 W (50 W + 50 W)
(10 % T.H.D.)
Output terminals: Front speakers; 6 ohms
(CD-C622) Rear Speakers; 16 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
Output terminals: Speakers; 6 ohms
(CD-C2900) Headphones; 16-50 ohms
(recommended; 32 ohms)
Input terminal: Video/Auxiliary (audio signal);
500 mV/47 kohms
Tuner section
Frequency range: FM; 87.5 - 108 MHz
AM; 530 - 1,720 kHz
Cassette deck section
Frequency response: 50 - 14,000 Hz (Normal tape)
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/
playback)
Wow and flutter: 0.15 % (WRMS)
Specifications for this model are subject to change without
prior notice.
SPECIFICATIONS
CD-C622/C2900
