ensure a more precise plotting.
When you want to plot drawings, move the Pen holder vertically as little as possible. That will
In case of drawings, there may be a shear of about 0.256 mm
(0.01 inch) in the X axis direction. The shear in the Y axis direction may increase to about
1.0% in case of roll paper or 70-micrometer sheet paper and to about 5.0% in case of sheet
paper thicker than 70-micrometers if the pen holder is of ten moved vertically.
dealer.
® EA-850B (a set of four black pens)
® EA-850C (a set of four pens: black, blue, green, and red)
Range of the Pen and the paper movement
When you purchase ballpoint pens, specify the CE-515P Ballpoint Pens from your local Sharp
The size of the drawing to be plotted is limited in width since the maximum size of the paper to
be used on this plotter is A4.
to create a program for the entire drawing and then specify the part that you want.
If you wish to plot only one part of a drawing, it is sometimes best
It is also
possible to make very large drawings by creating pieces of the drawing on different sheets and then
assembling the sheets to form one large drawing.
If you use this function, you can draw the part of the drawing which will be plotted on the paper
and draw other parts of the drawing as if the pen could move to those parts.
Be careful that the plotting ranges vary according to the type of the paper as is shown below.
In such cases, the scissoring function is useful,
Paper type
Steps ’ AB PAPER AS BS US LETTER
X direction 410 480 650 820 960
+Y direction 30 999 30 30 30
—Y direction 601 999 919 1149 1354
® Roll paper can be cut only in the X axis direction.
® With sheet paper,
in the Y axis direction, you will enter the
L
ey
if you proceed more than 30 steps
scissoring
area.” Therefore if you plot large letters on the first
line,
the upper parts of the letters might not be piotted.
In these cases, feed the paper beforehand using the LF
command {instead of the Paper Feed Key) and then run
the plotting instruction.
® Although the scissoring function is useful, you must be
careful when using it. If you make a mistake in creating
the program, the whole drawing may be drawn in the
scissoring area and nothing will show on the paper.
12
SN
(1 step = 0.2 mm (0.008 in.)}
ONNUN NN NN NN
r+Y
[
LLLL
LSS
S
r
?
/
T/
LSS
S
NN N N N N
SIS
/
\i\\
ONONONON
Slanting lines represent the
"scissoring area’’
/.
