Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
35
32K-S400,CK32S40
36K-S400,CK36S40
å D751 RH-DX0441CEZZ J Diode AC
or
RH-DX0220CEZZ AB
å D752 RH-DX0441CEZZ J Diode AC
or
RH-DX0220CEZZ AB
å D753 RH-DX0441CEZZ J Diode AC
or
RH-DX0220CEZZ AB
å D754 RH-DX0441CEZZ J Diode AC
or
RH-DX0220CEZZ
D755 VHD1SS119//-1 J Diode AB
D756 VHD1SS119//-1 J Diode AB
å VA701 RH-VX0035CEZZ J Varistor AF
PACKAGED CIRCUITS
å PR701 RMPTP0059CEZZ J Packaged Circuit AH
or
RMPTP0056CEZZ AH
X801 RCRSB0001PEZZ R Crystal AL
FILTERS
CF301 RFiLC0029TAZZ J Filter AD
CF302 RFiLC0267CEZZ J Filter AD
CF401 RFiLC0013CEZZ J Filter AE
CF631 RFiLA0034CEZZ J Filter AD
CF2040 RFiLC0121GEZZ J Filter AD
SF201 RFiLC0405CEZZ J SAW Filter AH
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 RCiLi0588CEZZ J IF Coil AF
or
RCiLi0622CEZZ
L301 VP-XF8R2K0000 J Peaking 8.2µH AB
L302 RCiLi0613CEZZ J IF Coil AE
L401 VP-XF6R8K0000 J Peaking 6.8µH AB
L402 VP-XF3R3K0000 J Peaking 3.3µH AB
L403 VP-XF8R2K0000 J Peaking 8.2µH AB
L404 VP-XF8R2K0000 J Peaking 8.2µH AB
L671 RCiLZ0720CEZZ J Coil (32K-S400, CK32S40)
L671 RCiLZ0868CEZZ J Coil (36K-S400, CK36S40) AM
L672 RCiLZ0789CEZZ J Coil AK
å L701 RCiLF0273CEZZ J Coil AM
or
RCiLF0232CEZZ AL
å L702 RCiLF0025PEZZ M Coil
or
RCiLF0273CEZZ AM
or
RCiLF0232CEZZ AL
or
RCiLF0133CEZZ
L705 RCiLP0179CEZZ J Coil AD
or
RCiLP0226CEZZ
L729 RCiLP0179CEZZ J Coil AD
or
RCiLP0226CEZZ
L821 VP-XF680K0000 J Peaking 68µH AB
L2040 RCiLB0159CEZZ J Oscillation Coil AF
DL421 RCiLZ0938CEZZ J Coil AW
TRANSFORMERS
å T601 RTRNZ0057PEZZ R H-driver AK
çå T602 RTRNF0021MEZZ J H-out (32K-S400, CK32S40)
çå T602 RTRNF0022MEZZ J H-out (36K-S400, CK36S40)
å T701 RTRNP0518CEZZ J Power AN
å T702 RTRNZ0006MEZZ J Transformer
CONTROLS
R502 RVR-M4334CEZZ J 10k(B) V-line AC
R676 RVR-M4334CEZZ J 10k(B) H-line AC
R678 RVR-M4336CEZZ J 22k(B) H-size AC
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C52 VCSATA1CE226K J 22 16V Tantalum AD
C53 VCEA0A1HW105M J 1 50V EL. AB
C54 VCEA0A1HW225M J 2.2 50V EL. AB
C55 VCEA0A1CW108M J 1000 16V EL. AD
C103 VCEA0A1CW228M J 2200 16V EL. AC
C201 VCKYCY1HB102K J 1000p 50V Ceramic AA
C202 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HB102K J 1000p 50V Ceramic AA
C204 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW337M J 330 16V EL. AC
C207 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYCY1HB102K J 1000p 50V Ceramic AA
C301 VCCCCY1HH330J J 33p 50V Ceramic AA
C302 VCCCCY1HH151J J 150p 50V Ceramic AA
C303 VCCCCY1HH390J J 39p 50V Ceramic AA
C307 VCCCCY1HH1R5C J 1.5p 50V Ceramic AD
C308 VCKYCY1HB102K J 1000p 50V Ceramic AA
C309 VCEA0A1CW337M J 330 16V EL. AC
C312 VCEA0A1CW476M J 47 16V EL. AB
C360 VCEA0A1HW225M J 2.2 50V EL. AB
C361 VCEA0A1HW225M J 2.2 50V EL. AB
C364 VCEA0A1EW107M J 100 25V EL. AC
C365 VCEA0A0JW107M J 100 6.3V EL. AB
C368 VCEA0A1CW477M J 470 16V EL. AC
C369 VCEA0A1CW477M J 470 16V EL. AC
C370 VCEA0A0JW107M J 100 6.3V EL. AB
C371 RC-QZA104TAYK J 0.1 50V Mylar AB
C372 RC-QZA104TAYK J 0.1 50V Mylar AB
C380 RC-QZA103TAYK J 0.01 50V Mylar AA
PWB-A: DUNTK9513WEK0(32K-S400, CK32S40)
PWB-A: DUNTK9513WEK1(36K-S400, CK36S40)
MAIN UNIT (Continued)
