Sharp CK32S4 User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
37
32K-S400,CK32S40
36K-S400,CK36S40
å C725 RC-EZ0698CEZZ J 330 160V EL.
or (36K-S400, CK36S40)
RC-EZ0494CEZZ
or
RC-EZ0662CEZZ
C726 RC-KZ0338CEZZ J 560p 2kV Ceramic AD
C727 RC-KZ0338CEZZ J 560p 2kV Ceramic AD
C729 VCEA0A1CW106M J 10 16V EL. AB
C730 VCEA0A1EW108M J 1000 25V EL. AD
C731 VCEA0A1CW108M J 1000 16V EL. AD
C732 VCKYPA2HB102K J 1000p 500V Ceramic AA
C741 VCKYPA2HB102K J 1000p 500V Ceramic AA
C742 VCKYPA2HB102K J 1000p 500V Ceramic AA
C751 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C753 VCEA0A1CW107M J 100 16V EL. AC
C755 VCEA0A1CW476M J 47 16V EL. AB
C772 VCEA0A1VW477M J 470 35V EL. AB
C773 VCCSPA1HL101J J 100p 50V Ceramic AA
C801 RC-QZA223TAYK J 0.022 50V Mylar AB
C802 VCEA0A1HW474M J 0.47 50V EL. AB
C803 VCCCCY1HH110J J 11p 50V Ceramic AA
C804 VCKYCY1CB104K J 0.1 16V Ceramic AB
C805 VCKYCY1CB104K J 0.1 16V Ceramic AB
C806 VCKYCY1CB104K J 0.1 16V Ceramic AB
C807 VCCCCY1HH221J J 220p 50V Ceramic AA
C821 VCKYCY1HB103K J 0.01 50V Ceramic AA
C822 VCCCCY1HH150J J 15p 50V Ceramic AA
C823 VCCCCY1HH150J J 15p 50V Ceramic AA
C824 VCKYCY1HB103K J 0.01 50V Ceramic AA
C825 VCKYCY1HB103K J 0.01 50V Ceramic AA
C901 VCEA0A1HW335M J 3.3 50V EL. AB
C903 VCEA0A1HW335M J 3.3 50V EL. AB
C922 VCEA0A1HW335M J 3.3 50V EL. AB
C923 VCEA0A1HW335M J 3.3 50V EL. AB
C925 VCEA0A1CW476M J 47 16V EL. AB
C926 VCEA0A1CW476M J 47 16V EL. AB
C927 VCKYCY1HB103K J 0.01 50V Ceramic AA
C928 VCKYCY1HB103K J 0.01 50V Ceramic AA
C929 VCEA0A1CW106M J 10 16V EL. AB
C930 VCEA0A1CW106M J 10 16V EL. AB
C951 VCEA0A1CW106M J 10 16V EL. AB
C952 VCEA0A1CW106M J 10 16V EL. AB
C954 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C955 VCEA0A1CW106M J 10 16V EL. AB
C956 VCEA0A1CW337M J 330 16V EL. AC
C1601 VCEA0A1CW106M J 10 16V EL. AB
C1602 VCCCCY1HH470J J 47p 50V Ceramic AA
C1603 VCKYCY1HB221K J 220p 50V Ceramic AA
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1 50V EL. AB
C2060 VCKYCY1CB104K J 0.1 16V Ceramic AB
C2061 VCCCCY1HH101J J 100p 50V Ceramic AA
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2063 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C2201 VCKYCY1HB472K J 4700p 50V Ceramic AA
C2202 VCCCCY1HH390J J 39p 50V Ceramic AA
C3001 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3003 RC-QZA123TAYK J 0.012 50V Mylar AB
C3004 VCEA0A1HW105M J 1 50V EL. AB
C3005 VCEA0A1HW475M J 4.7 50V EL. AB
C3006 VCEA0A1HW106M J 10 50V EL. AB
C3007 VCEA0A1HW475M J 4.7 50V EL. AB
C3008 VCKYCY1HF103Z J 0 01 50V Ceramic AA
C3009 VCEA0A1CW227M J 220 16V EL. AC
C3010 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3011 VCEA0A1HW475M J 4.7 50V EL. AB
C3012 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA
C3014 RC-QZA473TAYK J 0.047 50V Mylar AB
C3015 VCSATA1CE335K J 3 3 16V Tantalum AC
C3016 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3017 VCSATA1CE106K J 10 16V Tantalum AD
C3018 VCEA0A1HW105M J 1 50V EL. AB
C3021 VCEA0A1HW475M J 4.7 50V EL. AB
C3022 VCEA0A1HW475M J 4.7 50V EL. AB
C3023 VCEA0A1HW475M J 4.7 50V EL. AB
C3024 VCEA0A1HW475M J 4.7 50V EL. AB
C3025 VCKYCY1HB103K J 0.01 50V Ceramic AA
C3026 VCKYCY1HB103K J 0 01 50V Ceramic AA
C3027 VCKYCY1HB103K J 0.01 50V Ceramic AA
C3028 VCKYCY1HB103K J 0.01 50V Ceramic AA
C3029 VCKYCY1HB103K J 0.01 50V Ceramic AA
C3030 VCKYCY1HB103K J 0.01 50V Ceramic AA
C3201 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3202 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3203 VCEA0A1HW475M J 4.7 50V EL. AB
C3204 VCEA0A1CW106M J 10 16V EL. AB
C3205 VCEA0A1CW106M J 10 16V EL. AB
C3206 VCKYCY1HB103K J 0.01 50V Ceramic AA
C3207 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3208 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
RESISTORS
[M-Ox.··· M-Ox., M-Film.··· M-Film]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ4 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ8 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ11 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ12 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ13 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA
PWB-A: DUNTK9513WEK0(32K-S400, CK32S40)
PWB-A: DUNTK9513WEK1(36K-S400, CK36S40)
MAIN UNIT (Continued)
