Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
41
32K-S400,CK32S40
36K-S400,CK36S40
R3011 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R3012 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R3017 VRD-RA2BE102J J 1k 1/8W Carbon AA
R3018 VRD-RA2BE102J J 1k 1/8W Carbon AA
R3201 VRS-CY1JF225J J 2.2M 1/16W M-Ox. AA
R3202 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R3203 VRD-RA2BE103J J 10k 1/8W Carbon AA
SWITCH
S502 QSW-B0015CEZZ J V-Center AC
MISCELLANEOUS PARTS
å RY701 RRLYU0036CEZZ J Relay AM
or
RRLYU0028CEZZ AK
å F701 QFS-B5023CEZZ J Fuse 5A (AC125V) AC
FB601 RBLN-0047CEZZ J Ferrite Bead AB
FB671 RBLN-0047CEZZ J Ferrite Bead AB
FB701 RBLN-0037CEZZ J Ferrite Bead AB
FB702 RBLN-0036CEZZ J Ferrite Bead AB
FB704 RBLN-0037CEZZ J Ferrite Bead AB
FB706 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
J921 QSOCD0430CEZZ J Socket, S-Video AE
P351 QPLGN0461CEZZ J Plug, 4-pin(S) AB
P401 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
P601 QPLGN0161FJZZ M Plug, 6-pin(K)
P621 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
P651 QPLGN0361CEZZ J Plug, 3-pin(TP651~3) AB
P701 QPLGN0404CEZZ J Plug, 4-pin(EJ) AB
P703 QPLGN0269GEZZ J Plug, 2-pin(P) AB
P901 QPLGN0661CEZZ J Plug, 6-pin(EJ) AD
P2401 QPLGN0561CEZZ J Plug, 5-pin AB
P2403 QPLGN0461CEZZ J Plug, 4-pin(YR) AB
RDA361 PRDAR5006MEFW M Heat Sink, IC361
RDA501 PRDAR0234PEFW R Heat Sink, IC501 AH
RDA601 PRDAR0150PEFW R Heat Sink, Q601 AL
RDA671 PRDAR1007MEFW M Heat Sink, Q673
RDA701 PRDAR1006MEFW M Heat Sink, IC701
RDA750 PRDAR5072CEFW J Heat Sink, IC751 AC
TAN921 QTANJ0523CEZZ J A/V Terminal AG
PWB-A: DUNTK9513WEK0(32K-S400, CK32S40)
PWB-A: DUNTK9513WEK1(36K-S400, CK36S40)
MAIN UNIT (Continued)
PWB-B: DUNTK9303WEK3(32K-S400, CK32S40)
PWB-B: DUNTK9303WEK4(36K-S400, CK36S40)
CRT UNIT
TRANSISTORS
Q850 VS2SC4544LB2E J 2SC4544 AD
Q851 VS2SC4544LB2E J 2SC4544 AD
Q852 VS2SC4544LB2E J 2SC4544 AD
Q853 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q854 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q855 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q894 VS2SA1266-Y-1 J 2SA1266(Y) AA
DIODES
D850 VHD1SS119//-1 J Diode AB
D851 VHD1SS119//-1 J Diode AB
D852 VHD1SS119//-1 J Diode AB
D894 VHD1SS119//-1 J Diode AB
D895 VHD1SS119//-1 J Diode AB
D896 RH-EX0616GEZZ J Zener Diode, 5.6V AA
or
RH-EX0298CEZZ
D897 VHD1SS119//-1 J Diode AB
D898 VHD1SS119//-1 J Diode AB
COILS
L852 VP-MK221K0000 J Peaking 220µH AB
L853 VP-MK221K0000 J Peaking 220µH AB
L854 VP-MK221K0000 J Peaking 220µH AB
CAPACITORS
[EL.··· Electrolytic]
C850 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C851 VCEA0A1CW476M J 47 16V EL. AB
C876 VCCSPA1HL561J J 560p 50V Ceramic AA
C877 VCCSPA1HL471J J 470p 50V Ceramic AA
C878 VCCSPA1HL561J J 560p 50V Ceramic AA
C880 RC-KZ0153CEZZ J 0.001 3kV Ceramic AB
C892 VCEA0A1CW106M J 10 16V EL. AB
C893 VCEA0A1CW106M J 10 16V EL. AB
C895 VCEA0A1CW226M J 22 16V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide]
R849 VRD-RA2BE151J J 150 1/8W Carbon AA
R850 VRD-RA2BE561J J 560 1/8W Carbon AA
R851 VRD-RA2BE561J J 560 1/8W Carbon AA
R852 VRD-RA2BE561J J 560 1/8W Carbon AA
R854 VRD-RA2BE151J J 150 1/8W Carbon AA
R855 VRD-RA2BE151J J 150 1/8W Carbon AA
R856 VRD-RA2BE121J J 120 1/8W Carbon AA
R857 VRD-RA2BE121J J 120 1/8W Carbon AA
R858 VRD-RA2BE121J J 120 1/8W Carbon AA
å R859 VRS-VV3DB273J J 27k 2W M-Ox. AA
å R860 VRS-VV3DB273J J 27k 2W M-Ox. AA
å R861 VRS-VV3DB273J J 27k 2W M-Ox. AA
å R862 VRS-VV3DB273J J 27k 2W M-Ox. AA
å R863 VRS-VV3DB273J J 27k 2W M-Ox. AA
