Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
43
32K-S400,CK32S40
36K-S400,CK36S40
INTEGRATED CIRCUITS
IC1701 VHiMM1117XF1E M MM1117XFBE
IC1781 VHiKA7805Pi-1 R KIA7805PI AE
IC1801 VHiM65667FP-1 M M65667FP
TRANSISTORS
Q1721 VS2SD601AR/-1 J 2SD601 AC
Q1741 VS2SB709AR/-1 J 2SB709 AC
Q1742 VS2SB709AR/-1 J 2SB709 AC
Q1761 VS2SB709AR/-1 J 2SB709 AC
Q1762 VS2SB709AR/-1 J 2SB709 AC
Q1791 VS2SC1959Y/1E J 2SC1959 AC
Q1861 VS2SB709AR/-1 J 2SB709 AC
Q1881 VS2SD601AR/-1 J 2SD601 AC
Q1882 VS2SD601AR/-1 J 2SD601 AC
Q1883 VS2SD601AR/-1 J 2SD601 AC
DIODES
D1791 RH-EX0604GEZZ J Zener Diode, 4.3V AB
D1801 VHD1SS119//-1 J Diode AB
D1821 VHD1SS119//-1 J Diode AB
CRYSTAL
X1861 RCRSB0241CEZZ M Crystal
COILS
L1721 VP-XF680K0000 J Peaking 68µH AB
L1801 VP-XF100K0000 J Peaking 10µH AB
L1821 VP-XF100K0000 J Peaking 10µH AB
L1861 VP-XF100K0000 J Peaking 10µH AB
L1862 VP-XF100K0000 J Peaking 10µH AB
L1863 VP-XF100K0000 J Peaking 10µH AB
CAPACITORS
[EL.··· Electrolytic]
C1701 VCEA0A1HW475M J 4.7 50V EL. AB
C1702 VCEA0A1HW475M J 4.7 50V EL. AB
C1703 VCEA0A1HW475M J 4.7 50V EL. AB
C1721 VCEA0A1HW106M J 10 50V EL. AB
C1722 VCCCCY1HH330J J 33p 50V Ceramic AA
C1741 RC-QZA473TAYJ J 0.047 50V Mylar AB
C1742 VCEA0A1HW105M J 1 50V EL. AB
C1743 RC-QZA472TAYJ J 4700p 50V Mylar AB
C1761 RC-QZA473TAYJ J 0.047 50V Mylar AB
C1762 VCEA0A1HW105M J 1 50V EL. AB
C1763 RC-QZA682TAYJ J 6800p 50V Mylar AB
C1781 VCEA0A1CW476M J 47 16V EL. AB
C1791 VCEA0A1AW107M J 100 10V EL. AB
C1792 VCEA0A1AW107M J 100 10V EL. AB
C1801 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1802 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1803 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1804 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1805 VCEA0A1HW106M J 10 50V EL. AB
C1806 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1807 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1809 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1810 VCEA0A1CW336M J 33 16V EL. AB
C1811 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1812 VCEA0A1HW106M J 10 50V EL. AB
C1821 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1822 VCEA0A1HW106M J 10 50V EL. AB
C1841 VCEA0A1HW106M J 10 50V EL. AB
C1842 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1843 VCCCCY1HH680J J 68p 50V Ceramic AA
C1845 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1846 VCCCCY1HH151J J 150p 50V Ceramic AA
C1847 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1848 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1849 VCEA0A1HW106M J 10 50V EL. AB
C1850 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1851 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1861 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1862 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1863 VCCCCY1HH270J J 27p 50V Ceramic AA
C1865 RC-QZA154TAYJ J 0.15 50V Mylar AC
C1866 RC-QZA103TAYJ J 0.01 50V Mylar AB
C1867 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1868 VCFYSA1HB474J J 0.47 50V Mylar AC
C1869 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1870 VCEA0A1HW106M J 10 50V EL. AB
C1871 VCEA0A1HW106M J 10 50V EL. AB
C1872 VCKYCY1HF103Z J 0.01 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ4 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ8 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ11 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R1701 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1702 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1703 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1704 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1705 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1706 VRS-CY1JF474J J 470k 1/16W M-Ox. AA
R1721 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R1722 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1723 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA
R1724 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1741 VRD-RA2BE102J J 1k 1/8W Carbon AA
R1742 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1743 VRS-CY1JF151J J 150 1/16W M-Ox. AA
R1744 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
PWB-R: DUNTK9511WEK1
P-IN-P UNIT
