9
32K-S400, CK32S40
36K-S400, CK36S40
SERVICE
NUMBER
DATA
ADJUSTMENT CONTENTS
ADJUSTMENT ITEM
RANGE
INITIAL VALUE
NECESSARY
UNNECESSARY
ADJUSTMENT
NOTES
PART REPLACED
IC2001
IC2101 X
IC3001 X
CRT X
IC201
X
X
IC1801
Data is stored in IC2101.
The adjustment is needed to compensate for characteristics
of parts including IC201 and MTS level (M01).
Holding down both the CH-up/down bottons on the TV set in
the service mode for more than 2 seconds will automatically
write the above initial values into IC2101. Then perform a
complete adjustment.
Adjust items related to picture tube only.
Adjust items related to MTS only (M01~M05).
Table - A
Holding down both the CH-up/down buttons on the TV set at service mode for more than 2 seconds will automatically
write the above initial values into IC2101.
S01 PICTURE 55 00-7F
S02 TINT 46 00-7F
S03 COLOR 32 00-7F
S04 BRIGHTNESS 40 00-7F
S05 SHARPNESS 24 00-3F Must be set to "24"
S06 VERTICAL PHASE 00 00-07 Must be set to "00"
S07 HORIZONTAL PHASE 12 00-1F
S08 RF-AGC 23 00-3F
S09 VERTICAL AMP 20 00-3F
S10 VCO 2C 00-7F
S11 R CUT-OFF 00 00-FF
S12 G CUT -OFF 00 00-FF
S13 B CUT-OFF 00 00-FF
S14 G GAIN 7F 00-FF
S15 B GAIN 7F 00-FF
S16 TRAP(3.58MHz) 00 00 or 01 Must be set to "01"
S17 BALANCE 20 00-3F Must be set to "20"
S18 C.C.POSITION 17 00-7F
S19 Y-MUTE 00 00,01,03
"00" = NORMAL, "01" = No Y, "03" = No VERTICAL
OP OPTION (Set to each mode) 7B 00-7F Must be set to "7B"
M01 MTS LEVEL 0A 00-0F
M02 STEREO-VCO 20 00-3F
M03 FILTER 1C 00-3F
M04 LOW SEPARATION 20 00-3F
M05 HIGH SEPARATION 1B 00-3F
P01 P in P Y-LEVEL 30 00-7F
P02 P in P TINT 29 00-3F Must be set to "27"
P03 P in P COLOR 2E 00-7F
P04 P in P Y-OFFSET 09 00-1F Must be set to "09"
P05 P in P H-POSITION 0A 00-FF Must be set to "0A"
P06 P in P BURST GATE PULSE 00 00-7F Must be set to "00"
P07 P in P FREE RUN 0B 00-0F Must be set to "0B"
Adjust items related to P-IN-P only (P01~P07).
