Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
48
27N-S100, 27N-S180
CN27S10/14/18
PWB-B: DUNTK9510WEK1
CRT UNIT
TRANSISTORS
Q851 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q852 VS2SC3789//2E M 2SC3789 AA
or
VS2SC3619LB1E
Q853 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q854 VS2SC3789//2E M 2SC3789 AA
or
VS2SC3619LB1E
Q855 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q856 VS2SC3789//2E M 2SC3789 AA
or
VS2SC3619LB1E
Q881 VS2SA1266-Y-1 J 2SA1266(Y) AA
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D881 VHD1SS119//-1 J Diode AB
D882 VHD1SS119//-1 J Diode AB
D884 VHD1SS119//-1 J Diode AB
COIL
L851 VP-MK820K0000 J Peaking 82µH AB
CAPACITORS
[EL.··· Electrolytic]
C851 VCCSPA1HL391J J 390p 50V Ceramic AA
C852 VCCSPA1HL331J J 330p 50V Ceramic AA
C853 VCCSPA1HL391J J 390p 50V Ceramic AA
C854 RC-KZ0024CEZZ J 0.001 2kV Ceramic AC
or
VCKYPB3DE472Z 0.0047 2kV Ceramic
C883 VCEA0A1HW106M J 10 50V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide]
R851 VRD-RA2BE470J J 47 1/8W Carbon AA
R852 VRD-RA2BE181J J 180 1/8W Carbon AA
R853 VRD-RA2BE121J J 120 1/8W Carbon AA
R855 VRD-RA2BE471J J 470 1/8W Carbon AA
R856 VRD-RA2BE221J J 220 1/8W Carbon AA
å R857 VRS-VV3LB123J J 12k 3W M-Ox. AB
R858 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R859 VRD-RA2BE470J J 47 1/8W Carbon AA
R860 VRD-RA2BE181J J 180 1/8W Carbon AA
R861 VRD-RA2BE121J J 120 1/8W Carbon AA
R863 VRD-RA2BE471J J 470 1/8W Carbon AA
R864 VRD-RA2BE221J J 220 1/8W Carbon AA
å R865 VRS-VV3LB123J J 12k 3W M-Ox. AB
R866 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
R868 VRD-RA2BE181J J 180 1/8W Carbon AA
R869 VRD-RA2BE121J J 120 1/8W Carbon AA
R871 VRD-RA2BE471J J 470 1/8W Carbon AA
R872 VRD-RA2BE221J J 220 1/8W Carbon AA
å R873 VRS-VV3LB123J J 12k 3W M-Ox. AB
R874 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R881 VRD-RA2BE102J J 1k 1/8W Carbon AA
R882 VRD-RA2BE331J J 330 1/8W Carbon AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R895 VRD-RA2BE470J J 47 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0541CEZZ J Plug, 5-pin (GBN) AB
P852 QPLGN0441CEZZ J Plug, 4-pin (YBN) AB
SC851 QSOCV0937CEZZ M CRT Socket AF
INTEGRATED CIRCUIT
IC1501 VHiM52055FP-1 J M52055FP AH
TRANSISTORS
You can substitute "VS2SD601AR/-1" for "VS2SC2412KQ-1".
Q1501 VS2SC2412KQ-1 J 2SC2412K AA
Q1502 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA1037KR-1
Q1503 VS2SC2412KQ-1 J 2SC2412K AA
Q1504 VS2SC2412KQ-1 J 2SC2412K AA
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D1501 VHD1SS119//-1 J Diode AB
D1502 VHD1SS119//-1 J Diode AB
D1503 RH-EX0631GEZZ J Zener Diode, 9V AA
D1504 RH-EX0631GEZZ J Zener Diode, 9V AA
COILS
L1501 VP-XF6R8K0000 J Peaking 6.8µH AB
L1502 VP-XF6R8K0000 J Peaking 6.8µH AB
L1503 VP-XF8R2K0000 J Peaking 8.2µH AB
CAPACITORS
[EL.··· Electrolytic]
C1501 VCEA0A1CW106M J 10 16V EL. AB
C1502 VCCCCY1HH470J J 47p 50V Ceramic AA
C1503 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1504 VCCCCY1HH271J J 270p 50V Ceramic AA
C1505 VCCCCY1HH330J J 33p 50V Ceramic AA
C1506 VCCCCY1HH151J J 150p 50V Ceramic AA
C1507 VCCCCY1HH330J J 33p 50V Ceramic AA
C1508 VCE9GA1CW106M J 10 16V EL. (N.P) AB
C1509 VCEA0A1CW106M J 10 16V EL. AB
C1510 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1511 VCEA0A1CW106M J 10 16V EL. AB
C1512 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1513 VCKYCY1HF103Z J 0.01 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide]
R1501 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1502 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R1503 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R1504 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1505 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R1506 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1507 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1508 VRS-CY1JF561J J 560 1/16W M-Ox. AA
R1509 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1510 VRS-CY1JF181J J 180 1/16W M-Ox. AA
R1511 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R1512 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R1513 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R1514 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1515 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1516 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R1517 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1518 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1519 VRS-CY1JF101J J 100 1/16W M-Ox. AA
MISCELLANEOUS PARTS
P1501 QPLGN0585CEZZ J Plug, 5-pin (KA) AB
P1502 QPLGN0585CEZZ J Plug, 5-pin (KB) AD
P1503 QPLGN0661CEZZ J Plug, 6-pin (KC) AD
PWB-K: DUNTKA114WEK0 (27N-S100, CN27S14)
S-VIDEO UNIT
