Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
49
27N-S100, 27N-S180
CN27S10/14/18
INTEGRATED CIRCUIT
IC1401 VHiTC90A45F-1 J TC90A45F AM
IC1403 VHiKA78L05B-1 J KIA78L05BP AE
IC1451 VHiM52055FP-1 J M52055FP AH
TRANSISTORS
You can substitute "VS2SD601AR/-1" for "VS2SC2412KQ-1".
Q1401 VS2SC2412KQ-1 J 2SC2412K AA
Q1402 VS2SC2412KQ-1 J 2SC2412K AA
Q1403 VS2SC2412KQ-1 J 2SC2412K AA
Q1404 VS2SC2412KQ-1 J 2SC2412K AA
Q1405 VS2SC2412KQ-1 J 2SC2412K AA
Q1406 VS2SC2412KQ-1 J 2SC2412K AA
Q1407 VS2SC2412KQ-1 J 2SC2412K AA
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D1401 VHD1SS119//-1 J Diode AB
D1402 VHD1SS119//-1 J Diode AB
D1403 VHD1SS119//-1 J Diode AB
D1451 VHD1SS119//-1 J Diode AB
D1452 VHD1SS119//-1 J Diode AB
D1453 RH-EX0631GEZZ J Zener Diode, 9V AA
D1454 RH-EX0631GEZZ J Zener Diode, 9V AA
COILS
L1401 VP-XF100K0000 J Coil 10µH AB
L1402 VP-XF100K0000 J Coil 10µH AB
L1403 VP-XF150K0000 J Coil 15µH AB
L1405 VP-XF330K0000 J Coil 33µH AB
L1406 VP-XF100K0000 J Coil 10µH AB
CAPACITORS
[EL.··· Electrolytic]
C1401 VCCCCY1HH220J J 22p 50V Ceramic AA
C1402 VCFYSA1HB474J J 0.47 50V Mylar AC
C1403 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1404 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1405 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1406 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1407 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1408 VCEA0A1HW106M J 10 50V EL. AB
C1409 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1410 VCCCCY1HH181J J 180p 50V Ceramic AA
C1411 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1412 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1413 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1415 VCEA0A1CW476M J 47 16V EL. AB
C1416 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1417 VCCCCY1HH390J J 39p 50V Ceramic AA
C1418 VCEA0A1HW106M J 10 50V EL. AB
C1419 VCEA0A1HW106M J 10 50V EL. AB
C1420 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1421 VCCCCY1HH120J J 12p 50V Ceramic AA
C1423 VCCCCY1HH120J J 12p 50V Ceramic AA
C1424 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1425 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1426 VCKYCY1HB102K J 1000p 50V Ceramic AA
C1427 VCE9GA1CW106M J 10 16V EL. (N.P) AB
C1428 VCCCCY1HH270J J 27p 50V Ceramic AA
C1451 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1452 VCEA0A1CW106M J 10 16V EL. AB
C1453 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1454 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1455 VCE9GA1CW106M J 10 16V EL. (N.P) AB
RESISTORS
[M-Ox.··· Metal Oxide]
R1401 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1402 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1403 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
PWB-K: DUNTKA115WEK0 (27N-S180, CN27S18)
DIGICOM/S-VIDEO UNIT
R1404 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1405 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R1406 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1407 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1408 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R1409 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1410 VRS-CY1JF681J J 680 1/16W M-Ox. AA
R1411 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1412 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R1413 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R1414 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1415 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R1416 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R1417 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R1418 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R1419 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1420 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R1421 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R1422 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1425 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R1451 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1452 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1453 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R1454 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R1455 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
MISCELLANEOUS PARTS
P1401 QPLGN0585CEZZ J Plug, 5-pin (KA) AA
P1402 QPLGN0585CEZZ J Plug, 5-pin (KB) AA
P1451 QPLGN0661CEZZ J Plug, 6-pin (KC) AA
