Sharp CS-2635RH User Manual

9
Fig. 1
Printer cover
Fig. 2
Ink ribbon
Fig. 3
Ink ribbon
Reel
Reel shaft
1. Lift the paper holder up. (Fig. 1)
2. Fold the leading edge of the paper roll 3 to 5 cm.
(Do not fold it slantwise.) (Fig. 2)
3. Insert the paper roll from the left side of the paper
holder and make sure the paper roll is set in the
proper direction (with the paper feeding from the
bottom). (Fig. 3)
4. Insert the leading edge of the paper into the
opening directly behind the print mechanism.
(Fig. 4)
5. Press the paper feed key and feed the paper
under the edge of the paper cutter. (Fig. 5)
PAPER ROLL REPLACEMENT
Fig. 1
Paper holder
Fig. 2
3 cm – 5 cm
(1-3/16″ to
1-31/32″)
CS-2635RH(AXO)-Eng 12.6.20, 8:40 AMPage 9 AdobePageMaker6.5J/PPC

Sharp CS-2635RH Specifications

General

Type	Printing
Form factor	Desktop
Product color	Black, Silver
Digits	12 digits

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	250 x 345 x 87 mm
