PART NAMES
1 Air Outlet
2 Vertical louvers
3 Horizontal louvers
4 PLASMACLUSTER Lamp (blue)
5 Remote control signal receiver
window
6 AUX. Button
7 OPERATION Lamp (red
)
8 TIMER Lamp (orange
)
9 TURBO COOL Lamp (green
)
0 Air inlet
REAR VIEW
NOTE: Actual unit might vary slightly from above illustration.
FRONT VIEW
q Exhaust air outlet
w Exhaust adapter
e Exhaust hose
r Remote control hook
t Air filters
y Drainage nozzle and stopcock
u Power supply cord hooks
i Drainpipe nozzle and stopcock
o Power supply cord
p Power plug
a Casters (4)
E-4
1
2
3
4
5
6
7
8
9
0
0
0
q
w
e
r
t
y
u
i
o
p
a
