If the inner width of the window is between
24"(609mm)and36.8"(934mm)inclusive.
(1) Openthewindowsashandplace
the window panel on the window sill.
(2) Slidetheadjustmentpaneltotthe
window frame width.
(3) Securethewindowpanel tothe sill
with 3 screws.
If the inner width of the window is between
36.8"(934mm)and48"(1219mm)inclusive.
(1) Attachtheextensionpaneltothe
adjustment panel.
(2) Openthewindowsashandplace
the window panel on the window
sill.
(3) Slidetheadjustmentandextension
panels to fit the window frame
width.
(4) Securethewindowpaneltothewin-
dow sill with 4 screws.
5
Cut the foam seal (adhesive type)
A and B to the proper length and
attach it to the window panel.
Attach foam seal A to the window panel
and extension panel, and attach foam
seal B to the adjustment panel.
6
Close the window sash securely
against the Window panel.
7
Cut the foam seal to an appropri-
ate length and seal the opening
between the top of the inner win-
dow sash and the outer window
sash.
8
 Attachthebracketwithascrew.
Extension panel
24"-36.8"
36.8" - 48"
FoamsealA(adhesivetype)
Bracket
