EN-15
ENGLISH
If the inner width of the window is between
24"(609mm)and36.8"(934mm)inclusive.
(1) Openthewindowsashandplacethe
window panel on the window sill.
(2) Slide the adjustment panel to t the
window frame width.
(3) Securethewindowpaneltothesill
with 3 screws.
If the inner width of the window is between
36.8"(934mm)and48"(1219mm)inclusive.
(1) Attachtheextensionpaneltothe
adjustment panel.
(2) Openthewindowsashandplacethe
window panel on the window sill.
(3) Slide the adjustment and extension
panels to t the window frame width.
(4) Securethe window panel tothewin-
dow sill with 4 screws.
5
Cut the foam seal (adhesive type) A
and B to the proper length and at-
tach it to the window panel.
Attach foam seal A to the window panel
and extension panel, and attach foam seal
B to the adjustment panel.
6
Close the window sash securely
against the Window panel.
7
Cut the foam seal to an appropriate
length and seal the opening
between the side of the inner
window sash and the outer window
sash.
8
 Attachthebracketwithascrew.
Adjustment panel
Extension panel
24"- 36.8"
36.8"- 48"
Foam seal A
(adhesivetype)
Bracket
