FRONT & REAR PANEL/DISPLAY WINDOW
< Front Panel
1. OPERATE Switch Button
Turns the unit’s power on and off.
2. OPEN/CLOSE Button
Opens or closes the disc tray.
3. Disc Tray
To place DVD, VCD, Audio CD, and MP3 discs on.
4. STOP Button
Stops playback.
5. PLAY Button
Plays the inserted disc.
6. STANDBY Indicator
LED Indicator of Standby mode.
7. Display Window
Displays operation information.
8.
9
SKIP Button
Goes to the previous chapter/track during playback with
DVD/VCD/Audio CD. It functions as “Go to the previous page” in the
PBC menu with VCD discs.
9.
7
REV Button
Reverse scan.
10. FWD
8
Button
Forward scan.
11. SKIP
:
Button
Goes to the next chapter/track during playback with
DVD/VCD/Audio CD. It functions as “Go to the next page” in the
PBC menu with VCD discs.
< Rear Panel
1. Composite Video Output Jack
2. S-Video Output Jack
3. R/L Audio Output Jacks
4. Coaxial Digital Audio Output Jack
5. AV1 (TV) (SCART1)
6. AV2 (SCART2)
