Sharp DV-NC70 - Page 88

105
DV-NC70/W
DV-NC70X/RU
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
R7736 VRS-CY1JF101JS 100 1/16W Metal Oxide AA
R7737 VRD-RA2BE101JY 100 1/8W Carbon AA
R7738 VRS-CY1JF101JS 100 1/16W Metal Oxide AA
R7739 VRS-CY1JF101JS 100 1/16W Metal Oxide AA
SWITCHES
S701 QSW-F0042AJZZ Switch, REC Tip SW AG
S704 QSW-RA001WJZZ Switch AF
BALUNES
JA292 RBLN-0090GEZZY Balun, BLN-0090GE AB
JA317 RBLN-0090GEZZY Balun, BLN-0090GE AB
FB702 RBLN-0090GEZZY Balun, BLN-0090GE AB
FB1202 RBLN-0077TAZZS Balun, BLN-0077TA AB
FB1203 RBLN-0077TAZZS Balun, BLN-0077TA AB
MISCELLANEOUS PARTS
CN202 QSOCN1199REZZ Socket, 11Pin AD
CN501 QSOCN2999REZZ Socket, 29Pin AE
CN801 QSOCN0895REZZ Socket, 8Pin AC
CN802 QSOCN1095REZZ Socket, 10Pin AC
CN803 QSOCN1595REZZ Socket, 15Pin AD
J1201 QSOCD0445AJZZ Socket, 5Pin AF
J1202 QJAKL0025AJZZ Jack, 14Pin AH
J1204 QTANJA020WJZZ Terminal, 5Pin
J1205 QJAKGA010WJZZ Jack, 5Pin AG
P302 QSOCN1899REZZ Socket, 18Pin AD
P603 QCNCMA033WJZZ Connector, 15Pin
P701 QPLGZ1283GEZZ Plug, 12Pin AE
P7003 QPLGN1278GEZZ Plug, 12Pin AC
SC301 QSOCNA006WJZZ Socket, 9PIn AD
SC601 QSOCN0611REN1 Socket, 6Pin AC
SC602 QSOCZ0293GEZZ Socket, 2Pin AC
TP201 QPLGN0447REZZ Plug, 4Pin AA
W851 LHLDZ2185AJ00 Holder AB
W852 LHLDZ2185AJ00 Holder AB
DUNTKB518TEV1
MPX/SKEW PWB Unit
INTEGRATED CIRCUITS
IC1701 VHiMSP3417G-1Q MSP3417G, MPX Decoder AY
IC4261 VHiTL8857F/-1Y TL8857F, NTSC SKEW AM
Compensator
TRANSISTORS
Q4261 VS2PD601AR/-1Y 2PD601AR AB
Q4262 VS2PD601AR/-1Y 2PD601AR AB
Q4263 VS2PD601AR/-1Y 2PD601AR AB
Q4264 VS2PB709AR/-1Y 2PB709AR AB
PACKAGED CIRCUITS
X1701 RCRSB0249GEZZ+ Crystal, 18.432MHz AF
COILS
L1703 VP-XF100J0000+ Peaking, 10µHAA
L1704 VP-XF100J0000Y Peaking, 10µHAB
L4261 VP-ZK680K0000+ Peaking, 68µHAB
L4262 VP-ZK680K0000+ Peaking, 68µHAB
L4263 VP-XF330J0000+ Peaking, 33µHAB
CAPACITORS
C1701 VCCSD41HL220JY 22p 50V Ceramic AM
C1702 VCCCCY1HH470JY 47p 50V Ceramic AA
C1704 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C1705 VCEA9M1CW106M+ 10 16V Electrolytic AB
C1706 VCKYCY1HF103ZY 0.01 50V Ceramic AA
DUNTKB517TEV1(NC70W)
DUNTKB517TEV2(NC70)
DUNTKB517TEV3(NC70X/RU)
VCR Main PWB Unit(Continued)
C1707 VCEA9M1CW106M+ 10 16V Electrolytic AB
C1708 VCEA9M0JW226M+ 22 6.3V Electrolytic AB
C1709 VCEA9M1AW226M+ 22 10V Electrolytic AB
C1710 VCCCCY1HH5R0CY 5p 50V Ceramic AA
C1711 VCCCCY1HH6R0DY 6p 50V Ceramic AA
C1712 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C1713 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C1714 VCEA9M1HW105M+ 1 50V Electrolytic AB
C1715 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C1718 VCEA9M0JW226M+ 22 6.3V Electrolytic AB
C1720 VCCCCY1HH470JY 47p 50V Ceramic AA
C1723 VCEA9M1CW106M+ 10 16V Electrolytic AB
C1735 VCKYCY1HB122KY 1200p 50V Ceramic AA
C1738 VCKYCY1HB122KY 1200p 50V Ceramic AA
C1770 VCEA9M1CW106M+ 10 16V Electrolytic AB
C1771 VCEA9M1CW106M+ 10 16V Electrolytic AB
C4261 VCKYCY1CB104KY 0.1 16V Ceramic AB
C4262 VCKYCY1HB472KY 4700p 50V Ceramic AA
C4263 VCEA9M0JW476M+ 47 6.3V Electrolytic AB
C4264 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C4265 VCEA9M0JW476M+ 47 6.3V Electrolytic AB
C4266 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C4267 VCEA9M1HW105M+ 1 50V Electrolytic AB
C4268 VCKYCY1HF103ZY 0.01 50V Ceramic AA
C4269 VCEA9M0JW476M+ 47 6.3V Electrolytic AB
C4270 VCCCCY1HH330JY 33p 50V Ceramic AA
C4271 VCCCCY1HH2R0CY 2p 50V Ceramic AA
C4272 VCCCCY1HH330JY 33p 50V Ceramic AA
C4273 VCEA9A1CW476M+ 47 16V Electrolytic AB
C4274 VCEA9M1HW105M+ 1 50V Electrolytic AB
C4275 VCEA9M1HW105M+ 1 50V Electrolytic AB
C4276 VCEA9M1HW474M+ 0.47 50V Electrolytic AB
C4277 VCKYCY1HF103ZY 0.01 50V Ceramic AA
RESISTORS
R1701 VRD-RA2BE181JY 180 1/8W Carbon AA
R1703 VRS-CY1JF473JY 47k 1/16W Metal Oxide AA
R1710 VRD-RA2BE101JY 100 1/8W Carbon AA
R1711 VRD-RA2BE101JY 100 1/8W Carbon AA
R1714 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R1720 VRS-CY1JF103JY 10k 1/16W Metal Oxide AA
R1723 VRS-CY1JF103JY 10k 1/16W Metal Oxide AA
R4261 VRS-CY1JF821JY 820 1/16W Metal Oxide AA
R4262 VRS-CY1JF562JY 5.6k 1/16W Metal Oxide AA
R4263 VRS-CY1JF272JY 2.7k 1/16W Metal Oxide AA
R4264 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R4265 VRS-CY1JF271JY 270 1/16W Metal Oxide AA
R4266 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R4267 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R4268 VRS-CY1JF152JY 1.5k 1/16W Metal Oxide AA
R4269 VRS-CY1JF222JY 2.2k 1/16W Metal Oxide AA
R4270 VRS-CY1JF272JY 2.7k 1/16W Metal Oxide AA
R4271 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide AA
R4272 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
R4273 VRD-RA2BE103JY 10k 1/8W Carbon AA
R4274 VRS-CY1JF102JY 1k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
SC1701 QCNCWA086WJZZ Connector, 15Pin AD
SC1702 QSOCN1899REZZ Socket, 18Pin AD
