106
DV-NC70/W
DV-NC70X/RU
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
MECHANISM PARTS (DVD PART)
401 CMECD0211HJV2 Mecha Chasis Ass’yBS
401-1 LX-BZ3189GEZZ Guide Axis Pressing AB
Screw, x4
401-2 NGERH1330AJZZ Relay Gear1 AC
401-3 NGERH1341AJ00 Relay Gear2 AC
401-4 LX-WZ1030GE00 Relay Gear Washer AA
401-5 LX-BZ3163GEFN Motor Screw, x2 AC
401-6 QSW-M0066AJZZ In SW AD
401-7 DUNTKB233TEV1 Sled Motor PWB Unit —
401-8 RMOTV2022AJZZ Sled Motor AK
401-9 NGERH1333AJZZ Sled Motor Gear AB
401-10 NGERR1021AJZZ Double Action Rack AC
401-11 MSPRC0244AJZZ Rack Spring AB
401-12 NGERR1024AJZZ Rack AC
401-13 LX-HZ0083TAFF Rack Fixing Screw AA
401-14 QPLGN0680GEZZ Plug AB
409 PCUSG0126AJZZ Insulator, x4 AD
410 LX-HZ3117AJZZ Traverse Fixing Screw, x6 AC
413 QCNW-8552AJZZ Sled Wire AF
418 QCNW-A362WJZZ Pickup Relay FFC AD
419 MSLiP0014AJZZ Slide Rack AD
420 LHLDZ2144AJZZ Traverse Holder AD
421 QCNW-8375AJZZ Loading Wire AD
422 LHLDW1033CE00 Nylon Band Holder AA
423 RMOTM1097AJZZ Loading Motor AM
424 NPLYM0001AJZZ Loading Motor Pulley AB
425 QSW-B0011AJZZ Loading Motor Switch AE
426 NBLTK0068AJZZ Loading Belt AD
427 NGERH1332AJZZ Pulley Gear AC
428 NGERP1016AJZZ Tray Pinion AC
429 LCHSMA001WJZZ Base Chassis AL
431 LCRA-0012GEZZ Disc Clamper AF
432 LX-WZ0102GEFD York Washer AB
433 PMAGS1001GEZZ Clamper Magnet AF
434 GCOVA2164AJZZ Tray AH
435 LX-BZ3434AJFD Loading Motor Fixing AB
Screw, x2
SPAKCA310WJZZ Packing Case(NC70/W/X) —
SPAKCA315WJZZ Packing Case(NC70RU) —
SPAKP0209AJZZ Wrapping Paper —
SPAKXA023WJZZ Packing Add. —
SSAKA0001AJZZ Operation Manual —
Polyethylene Bag
TLABV0182AJZZ No. Label(NC70RU) —
TLABZA194WJZZ No. Label(NC70W) —
TLABZA121WJZZ No. Label(NC70) —
TLABZA122WJZZ No. Label(NC70X) —
PACKING PARTS
(NOT REPLACEMENT ITEM)
SUPPLIED ACCESSORIES
QCNW-8388AJZZ AV Cable AK
QCNW-8547AJZZ RF Cable AG
RRMCGA107WJSA Remote Control Unit AV
(NC70W)
RRMCGA114WJSA Remote Control Unit AV
(NC70/X/RU)
TiNS-A366WJZZ Operation Manual AN
(NC70/W/X)
TiNS-A368WJZZ Operation Manual
(NC70RU)
TGANEA002WJZZ Guarantee Card(NC70X) —
TGAN-A101WJZZ Guarantee Card(NC70RU) —
ACCESSORIES
(NOT REPLACEMENT ITEM)
