10
DW-71-H
2. Changing the airflow direction
3. Defrosting mode
(1) Necessity of defrosting
When the room temperature lowers below approx. 16 :, the temperature of cooler lowers below 0 :, resulting in frosting
of cooler which impedes air flow. Therefore defrosting must be performed timely.
(2) Start of defrosting
When the defrosting thermistor temperature sensor detects temperature of about 2.5 : or below and the IC timer
counts approx. 40 min., while the room temperature is below approx. 16 :, the defrosting operation is started.
(3) End of defrosting
When the defrosting thermistor temperature sensor detects about 12 :, the defrosting is ended, and the normal
operation is resumed.
The defrosting time is about 5 to 10 minutes.
(4) Hot gas defrosting system
In the defrosting mode the solenoid valve is actuated and opened, so that the hot gas flows in the arrow direction
shown in the figure to remove the frost on the cooler.
In the defrosting mode the solenoid valve is actuated and
opened, so that the hot gas flows in the arrow direction
shown in the figure to remove the frost on the cooler.
Upward
Diagonally downward
Push the lever upward.
To dehumidify your room
To dry clothes
Perform the 
drying clothes 
operation.
Push the lever downward.
Open the door
of the closet
and operate the
unit in front of it.
To dehumidify a closet or wall
Cooler
Capillary
Dryer filter
Condenser
Compressor
Solenoid valve
