4. Continuous drainage
1
2
3
4
1
2
3
4
You can continuously drain the water from the unit with the use of the right
draining facilities. Make sure to turn off and unplug the unit before carrying out
the following procedures.
Punch out the continuous
drainage hole.
Insert the drain hose elbow
into the hose and pass the
hose through the hole.
Push the drain hose elbow
into the unit.
Return the water tank.
Open the front door and
let the open end of the
hose pass through the
hole.
Remove the water tank and punch out the
continuous drainage hole on the back of
the unit using a screwdriver and finish the
edge with a knife.
Continuous draining hole
A commercially
available hose with a
15 mm inside diameter
10 mm or more
Drain hose elbow
Push the drain hose elbow into the draining
section of the unit until you hear a click.
Drain hose
elbow
The unit will not operate unless the tank has
been returned and properly positioned.
Water tank
