4. Printer
1) Printer specifications
ITEMS
Model name
CR-812A
No. of station 2 (Receipt/Journal)
Printing
system
Print wheel selective type
Printing
capacity
Receipt : Max. 10 chr.
Journal : Max. 10 chr.
Validation : Max. 20 chr./1 line
Character
size
Figure : 1.7mm (W) x 3.2mm (H)
Symbol : 2.4mm (W) x 3.2mm (H)
Print pitch Column distance : 3.35mm for between 1st and 2nd
column 3.0mm for after 3rd column
Row distance : 5.1mm
Print speed Approx. 2.5 lines/sec.
Paper feed
speed
Approx. 17 lines/sec. at receipt issued.
Reliability MCBF 2.5 million lines
Validation
form sensor
No
Near end
sensor
Journal side: No
Receipt side: No
Cutter Manual
Print wheel
layout
Parts code: 00BM731002300
2) Roll paper
Parts code DPAPR1006CSZZ
Dimension 44.5
m 0.5mm in width
Max. 80mm in diameter
Paper quality Journal/Receipt
Fine quality paper
Paper thickness : 0.06 to 0.09 mm
Paper weight : 52.3 to 64g/m
2
Validation form
Normal paper only
Thickness : 0.08 to 0.19 mm
Size : 115mm or more, 210mm or
under (W) x 70mm or more (H)
3) Validation paper
Paper quality Normal paper and pressure sensitive paper only
Thickness : 0.07 to 0.14 mm
Size : 115 mm or more (W) x 70 mm or more (H)
Printing area
4) Inking
Parts code NROLR6638RCZZ
Ink supply system Ink roller
Form Roller
Specification Material-rubber
Roller life Approx. 0.6 million lines
Print color Purple
5) Logo stamp
Material Porous rubber
Size 30mm (W) x 20mm (H)
Color Purple
Parts code for ink UINK1001CCZZ
5. Drawer
1) Drawer box and drawer
Model name SK423
Size 420(W) x 423(D) x 112(H) mm
Color Gray 368
Material Metal
Bell —
Release lever Standard equipment; Situated at the bottom
Drawer open sensor Standard equipment
