Positioning the drain hose
Ensure the drain hose is fixed, and the position does not move or become loose,
otherwise it will cause leakage and property loss.
The end of the drain hose may be positioned in three ways:
3.In a sink drain hose branch:
The end of the drain hose is connected to a sink drain
hose branch. The highest point of the drain hose must
be lower than 90cm.
2.In a floor drain directly:
Please ensure the drain hose height from the floor
drain is less than 90cm.
Note: the end of the drain hose cannot be immersed in
water.
1.Over the edge of a wash basin:
The end of the drain hose must be placed at lower
than 90cm from the ground. To avoid the influence of
the drain hose bending on water flow, secure it over
the edge of the wash basin with a hook or a piece of
string to prevent the drain hose from moving.
If you are using a screw type of water tap, use the
provided screw-type adaptor to connect to the water
tap as shown.
Installation
max. 90cm
max. 90cm
max. 90cm
14
