EN -10-
1
2
3
1-Detergent drawer
2-Programme knob
3-Elektronic Display and Additional
Functions
DETERGENT DRAWER
You can use the liquid level determination plate when you want to wash your laundry with liquid detergent. You
can use your liquid detergents in all programs without prewashing. Place the liquid detergent aparatus in the
second compartment (which is available inside the machine) of the detergent drawer (*) and set the detergent
amount. (Use the recommended amount of liquid detergent by detergent producers). Do not exceed the MAX
level, use only for liquid detergent, do not use this aparatus for powder detergent and take it out.)
Main wash detergent
Liquid Detergent Apparatus (*)
Softener
Compartment
Pre-wash detergent
compartment
Powder
detergent
spade (*)
Powder detergent
level stages
Main wash detergent compartment: In this compartment, only materials like detergent (liquid or powder),
lime preventer and such can be used.You can nd the liquid detergent aparatus inside your machine at rst
installation. (*)
Fabric conditioner, starch, detergent compartment: You can use softener for your laundry recommended
amount and type by the producer is recommended). Sometimes the fabric conditioners you use for your laundry
mar remain in this compartment. The reason for this is that the conditioner is not viscous. To prevent this situation,
more viscous liquid softeners are recommended to be used or the softener could be thinned and then used.
Pre-wash detergent compartment: This compartment must only be used when the pre-wash feature is selected.
Pre-wash feature is recommended for very dirty laundry. (*) Machinery specications may vary depending on the
product purchased.
PROGRAM KNOB
• You can select the programme you want to wash your laundry in through progra mme knob.
• You may set the programme selection operation by rotating the programme knob in both directions.
• Ensure that the programme knob is exactly on the programme you want to select.
ELECTRONIC DISPLAY
1. Display Panel
2. Water Temperature Adjustment Buton
1
2 3 4 5 6 7 8
3. Rpm Speed Adjustment Button
4. Dirtiness Level Selection
5. Auxiliary Functions
6. Extra Rinsing Auxiliary Function
7. Delay Timer Function
8. Start / Pause button
In the electronic display, you can see the washing water temperature of your machine, the wringing rpm, how long
the machine has to nish washing, whether the door of your machine is locked or not, the auxiliary functions you
have selected and the location of the programme you are running in your machine ( ) among
the washing sequence Furthermore, electronic display will warn you by means of fault symbols on the display
when a fault occurs on your machine and notify you of the completion of the washing programme by revealing
expression of “END” on the display as soon as the washing programme you have selected has nished as well.
CHAPTER -4: INTRODUCTION OF CONTROL PANEL SECTIONS
