GX-CD5100W

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PART

RANK

DESCRIPTION

[1] INTEGRATED CIRCUITS

IC1 VHILC78690E-1 BE CD Servo, LC78690E

IC2 VHILA6548NH-1 AL Focus / Tracking / Spin / Sled / Driver IC

IC101 VHIAN7345K/-1 AM Playback and REC Playback Amp,AN7345K

IC201 VHIKIA4558F-1 AF OP Amp IC

IC301 VHILA1832S/-1 AN FM IF Det/FM Mpx/AM IF,LA1832S

IC302 VHITA7358AP-1 AG FM Front End,TA7358AP

IC303 VHILC72131/-1 AP PLL(Tuner),LC72131

IC401 VHILC75341M-1 AM Audio Processor,LC75341M

IC601 RH-IXA043AWZZ AR Sound IC,XA043AW

IC701 RH-IXA098AW00 AW System Micom,XA098AW

IC702 VHIPST9140N-1 AE Reset IC,PST9140

IC801 VHIKIA7809AP1 AF Voltage Regulator,KIA7809AP

IC802 VHIKIA7805AP1 AF Voltage Regulator,KIA7805AP

IC803 VHIKIA34063AF AG DC-DC,A34063AF

IC804 VHILA4663N/-1 AQ 2ch Power IC,LA4663N

ICV704 VHI74VHCT08-1 AF Gate IC,74VHCT08

[2] TRANSISTORS

Q1 VSKTA1504GR-1 AB Silicon,PNP,KTA1504 GR

Q2 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y

Q3 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q101 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q102 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q103 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q104 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q105 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q106 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q107 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q108 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q109 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q110 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR

Q111 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q112 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR

Q113 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q115 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q117 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q118 VSKTA1273Y/-1 AE Silicon,PNP,KTA1273 Y

Q119 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q120 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q121 VSKTA1273Y/-1 AE Silicon,PNP,KTA1273 Y

Q122 VSKTA1273Y/-1 AE Silicon,PNP,KTA1273 Y

Q123 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q124 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q125 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q126 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q201 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q202 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q203 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q301 VSKTC2874B+-1 AC Silicon,NPN,KTC2874 B

Q302 VSKTC2874B+-1 AC Silicon,NPN,KTC2874 B

Q303 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q306 VSKTC2874B+-1 AC Silicon,NPN,KTC2874 B

Q307 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q308 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR

Q309 VSKRA107M//-1 AE Digital,PNP,KRA107 M

Q310 VSKRA107M//-1 AE Digital,PNP,KRA107 M

Q311 VSKRA107M//-1 AE Digital,PNP,KRA107 M

Q312 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q313 VSKTC3194Y/-1 AB Silicon,NPN,KTC3194 Y

Q701 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q702 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q703 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q704 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q801 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR

Q802 VSKTB772Y//-1 AB Silicon,PNP,KTB772 Y

Q803 VSKRC107M//-1 AC Digital,NPN,KRC107 M

Q804 VSKRC104M//-1 AC Digital,NPN,KRC104 M

Q805 VSKTB772Y//-1 AB Silicon,PNP,KTB772 Y

Q806 VSKTB772Y//-1 AB Silicon,PNP,KTB772 Y

Q807 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q808 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q809 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q810 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR

Q811 VSKRC104S//-1 AC Digital,NPN,KRC104 S

[3] DIODES

D1 VHDKDS160//-1 AB Silicon,KDS160

D102 VHD1N4148H/-1 AA Silicon,D1N4148H

D103 VHD1N4148H/-1 AA Silicon,D1N4148H

D104 VHD1N4148H/-1 AA Silicon,D1N4148H

D105 VHD1N4148H/-1 AA Silicon,D1N4148H

D107 VHD1N4148H/-1 AA Silicon,D1N4148H
