Sharp GX-CD5100W Service Manual

GX-CD5100W
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
D201 VHDKDS160//-1 AB Silicon,KDS160
D202 VHDKDS160//-1 AB Silicon,KDS160
D301 VHD1N4148H/-1 AA Silicon,D1N4148H
D302 VHD1N4148H/-1 AA Silicon,D1N4148H
D303 VHD1N4148H/-1 AA Silicon,D1N4148H
D304 VHD1N4148H/-1 AA Silicon,D1N4148H
D305 VHD1N4148H/-1 AA Silicon,D1N4148H
D306 VHD1N4148H/-1 AA Silicon,D1N4148H
D307 VHD1N4148H/-1 AA Silicon,D1N4148H
D308 VHD1N4148H/-1 AA Silicon,D1N4148H
D309 VHD1N4148H/-1 AA Silicon,D1N4148H
D310 VHD1N4148H/-1 AA Silicon,D1N4148H
D311 VHD1N4148H/-1 AA Silicon,D1N4148H
D312 VHD1N4148H/-1 AA Silicon,D1N4148H
D314 VHD1N4148H/-1 AA Silicon,D1N4148H
D315 VHD1N4148H/-1 AA Silicon,D1N4148H
D316 VHD1N4148H/-1 AA Silicon,D1N4148H
D317 VHD1N4148H/-1 AA Silicon,D1N4148H
D318 VHD1N4148H/-1 AA Silicon,D1N4148H
D319 VHD1N4148H/-1 AA Silicon,D1N4148H
D401 VHDKDS160//-1 AB Silicon,KDS160
D402 VHDKDS160//-1 AB Silicon,KDS160
D701 VHD1N4148H/-1 AA Silicon,D1N4148H
D702 VHD1N4148H/-1 AA Silicon,D1N4148H
D703 VHD1N4148H/-1 AA Silicon,D1N4148H
D801 VHD1N4148H/-1 AA Silicon,D1N4148H
D802 VHD1N4148H/-1 AA Silicon,D1N4148H
D803 VHD1N4148H/-1 AA Silicon,D1N4148H
D804 VHDERA83004-1 AC Silicon,A83004
D808 VHD1N4148H/-1 AA Silicon,D1N4148H
!
D901 VHDD10XB60F-1 AL Silicon,D1N4148H
!
D902 VHDDSRL204/-1 AB Silicon,D1N4148H
LED701 VHPA503YC2L-1 AG LED,Orange,503YC2L
LED702 VHPA304HD2A-1 AC LED,Red,304HD2A
VD301 VHCSVC348S/-1 AK Variable,VC348S
VD302 VHCSVC348S/-1 AK Variable,VC348S
VD303 VHCSVC348S/-1 AK Variable,VC348S
VD304 VHCSVC348S/-1 AK Variable,VC348S
VD305 VHCSVC211C/-1 AG Variable,VC211C
VD306 VHCSVC211C/-1 AG Variable,VC211C
ZD1 VHEDZ3R3BSA-1 AB Zener,3.3V,DZ3.3BSA
ZD301 VHEDZ4R7BSB-1 AB Zener,4.7V,DZ4.7BSB
ZD302 VHEDZ3R9BSB-1 AC Zener,3.9V,DZ3.9BSB
ZD701 VHEDZ5R1BSB-1 AC Zener,5.1V,DZ5.1BSB
[4] FILTERS
BFT301 RFILR0008AWZZ AE FM Band Pass Filter
CF301 RFILF0124AFZZ AD FM IF,10.7MHz
CF302 RFILA0009AWZZ AE AM IF
CF303 RFILF0003AWZZ AK 10.7MHz,Detector
[5] TRANSFORMERS
!
PT1 RTRNPA055AWZZ BB Power ( Main )
[6] COILS
FB1 RBLN-0061TAZZ AB Chip Ferrite Core
FB2 RBLN-0061TAZZ AB Chip Ferrite Core
L101 VP-MK331K0000 AB 330 µH,Choke
L301 RCILA0014AWZZ AE SW2 Antenna
L302 RCILAA004AWZZ AD 6.0µH,
L303 RCILA0052AWZZ AE MW Antenna
L304 VP-DH102K0000 AB 1 mH,Choke
L305 VP-MK102K0000 AB 1 mH,Choke
L306 VP-YF472J0000 AC 4.7 mH
L307 VP-MK561K0000 AB 560 µH,Choke
L308 VP-MK561K0000 AB 560 µH,Choke
L309 RCILBA003AWZZ AD SW2 Oscillation
L310 RCILBA002AWZZ AD SW1 Oscillation
L311 RCILI0019AWZZ AD AM IF
L312 RCILB0067AWZZ AD MW Oscillation
L313 VP-DH101K0000 AB 100 µH,Choke
L314 VP-DH101K0000 AB 100 µH,Choke
L315 RCILB0065AWZZ AC FM Oscillation
L316 RCILR0056AWZZ AB FM RF
L317 RCILI0017AWZZ AB FM IF
L801 RCILZA014AWZZ AK 100 µH,Coil
TC301 RTO-H1001AWZZ AF Trimmer
TC302 RTO-H1001AWZZ AF Trimmer
TC303 RTO-H1001AWZZ AF Trimmer
TC304 RTO-H1001AWZZ AF Trimmer
[3] DIODES
