Sharp GX-CD5100W Service Manual

GX-CD5100W
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[7] VIBRATORS/CRYSTALS
X301 92LCRSTL1425A AF Crystal,456 KHz
XL1 RCRM-0047AWZZ AE Ceramic,16.9344MHz
XL301 RCRSP0019AWZZ AF Crystal,4.5 MHz
XL701 RCRSP0011AWZZ AC Crystal,32.768 KHz
[8] CAPACITORS
C1 VCEAZA1AW107M AC 100µF,10V,Electrolytic
C2 VCKYCY1HB102K AA 0.001µF,50V
C3 VCEAZA1AW107M AC 100µF,10V,Electrolytic
C4 VCKYPA1HB103K AA 0.01µF,50V
C5 VCEAZA1EW476M AB 47µF,25V,Electrolytic
C6 RC-EZ0004AWZZ AD 3.3µF,16V,Electrolytic
C7 VCKYPA1HB102K AA 0.001µF,50V
C8 VCEAZA1AW476M AB 47µF,10V,Electrolytic
C11 VCEAZA1AW107M AC 100µF,10V,Electrolytic
C12 VCKYCY1HB472K AA 0.0047µF,50V
C13 VCKYCY1HB103K AA 0.01µF,50V
C14 VCKYCY1EF473Z AB 0.047µF,25V
C15 VCKYCY1CB563K AA 0.056µF,16V
C16 VCKYCY1HB103K AA 0.01µF,50V
C17 VCKYCY1CB563K AA 0.056µF,16V
C18 VCKYCY1HB103K AA 0.01µF,50V
C19 VCKYCY1CB104K AA 0.1µF,16V
C20 VCEAZA1AW107M AC 100µF,10V,Electrolytic
C21 VCKYCY1CB104K AA 0.1µF,16V
C22 VCEAZA1AW477M AC 470µF,10V,Electrolytic
C23 VCKYCY1CB104K AA 0.1µF,16V
C24 VCKYCY1CB104K AA 0.1µF,16V
C25 VCEAZA1HW224M AB 0.22µF,50V,Electrolytic
C26 VCKYCY1EF473Z AB 0.047µF,25V
C27 VCEAZA1AW107M AC 100µF,10V,Electrolytic
C28 VCKYCY1CB104K AA 0.1µF,16V
C29 VCEAZA1AW107M AC 100µF,10V,Electrolytic
C30 VCKYCY1CB104K AA 0.1µF,16V
C31 VCKYCY1CB104K AA 0.1µF,16V
C32 VCKYCY1CB104K AA 0.1µF,16V
C33 VCKYCY1CB104K AB 0.1µF,16V
C34 VCKYCY1CB104K AA 0.1µF,16V
C35 VCEAZA1HW105M AB 1µF,50V,Electrolytic
C36 VCEAZA1AW107M AC 100µF,10V,Electrolytic
C37 VCKYCY1CB104K AA 0.1µF,16V
C40 VCKYCY1CB104K AA 0.1µF,16V
C41 VCEAZA1HW106M AB 10µF,50V,Electrolytic
C42 VCEAZA1HW106M AB 10µF,50V,Electrolytic
C45 VCKYCY1CB104K AA 0.1µF,16V
C46 VCEAZA1AW477M AC 470µF,10V,Electrolytic
C47 VCKYCY1EF473Z AB 0.047µF,25V
C48 VCKYCY1HB103K AA 0.01µF,50V
C49 VCKYCY1EF223Z AB 0.022µF,25V
C50 VCCCCY1HH101J AA 100 pF( CH ),50V
C51 VCCCCY1HH101J AA 100 pF( CH ),50V
C52 VCCCCY1HH101J AA 100 pF( CH ),50V
C53 VCCCCY1HH101J AA 100 pF( CH ),50V
C54 VCKYCY1EF223Z AB 0.022µF,25V
C55 VCCCCY1HH101J AA 100 pF( CH ),50V
C56 VCCCCY1HH101J AA 100 pF( CH ),50V
C57 VCEAZA1AW107M AC 100µF,10V,Electrolytic
C58 VCKYBT1HB103K AA 0.01µF,50V
C59 VCKYCY1HB822K AA 0.0082µF,50V
C61 VCEAZA0JW108M AC 1000µF,6.3V,Electrolytic
C101 VCKYCY1HB222K AA 0.0022µF,50V
C103 VCKYCY1HB223K AA 0.022µF,50V
C104 VCKYCY1HB333K AA 0.033µF,50V
C105 VCEAZA1CW226M AC 22µF,16V,Electrolytic
C106 VCEAZA1CW107M AC 100µF,16V,Electrolytic
C107 VCKYCY1HB271K AA 270 pF,50V
C108 VCEAZA1CW476M AB 47µF,16V,Electrolytic
C109 VCKYCY1HB561K AA 270 pF,50V
C110 VCEAZA1CW107M AC 100µF,16V,Electrolytic
C111 VCKYCY1HB102K AA 0.001µF,50V
C112 VCKYCY1HB332K AA 0.0033µF,50V
C113 VCKYCY1HB331K AA 330 pF,50V
C114 VCKYCY1HB331K AA 330 pF,50V
C115 VCEAZA1CW476M AB 47µF,16V,Electrolytic
C116 VCEAZA1CW226M AC 22µF,16V,Electrolytic
C118 VCKYCY1HB102K AA 0.001µF,50V
C119 VCKYCY1HB102K AA 0.001µF,50V
C120 VCEAZA1CW226M AC 22µF,16V,Electrolytic
C121 VCEAZA1CW476M AB 47µF,16V,Electrolytic
C122 VCEAZA1CW476M AB 47µF,16V,Electrolytic
C123 VCKYCY1HB331K AA 330 pF,50V
C124 VCKYCY1HB331K AA 330 pF,50V
