HT-DV40H
8 – 16
M_DQM3/GPIO 161 Input/Output SDRAM data input/output mask for M_DD[31:24] , or GPIO[38]
M_DQM2/GPIO 162 Input/Output SDRAM data input/output mask for M_DD[23:16] , or GPIO[39]
GPIO/M_DD[23] 164 Input/Output GPIO[40] or SDRAM data bus bit 23
Symbol Pin # Input/Output Description
Priority selection Function Dir
sft_cfg0[5]=1’b1
SDRAM data input/output
mask for M_DD[31:24] (default)
Output
gpio_first[2][6] = 1 GPIO[38] Input/Output
sft_cfg13[3:0] = 4'b1011 IEC_RX Input
sft_cfg13[8:4] = 5'b01100 ADC_DATA
Input
sft_cfg2[3:2] = 3 UA0_RXD Input
sft_cfg1[8:6] = 3'b011 FL_MEM_CSALL_B Output
sft_cfg7[7:6] = 1 FL_PCMCIA_IOW_B Output
sft_cfg3[13:12] = 2 TV_HSYNC Input/Output
sft_cfg14[10:8] = 3'b010 TV_HSYNC_SRGB Output
sft_cfg4[15:13] = 3'b010 TV_HSYNC_PC Output
sft_cfg7[7:6] = 1 FL_PCMCIA_IOW_B Output
{sft_cfg20[5:3],sft_cfg14
[15:13]} = 6'b000101
INT0_7
Input
sft_cfg0[13:12] = 1 TV_LCD_G[2] Output
sfg_cfg16[11:8] = 4'b0101 FM_GPIOB[10] Input/Output
sfg_cfg16[15:12] = 4'b0100 FM_GPIOB[12] Input/Output
sfg_cfg17[3:0] = 4'b0001 FM_GPIOB[19] Input/Output
sfg_cfg18[3:0] = 4'b1001 FM_GPIOB[32] Input/Output
(other) GPIO[38] Input/Output
Priority selection Function Dir
sft_cfg0[4]=1’b1
SDRAM data input/output
mask for M_DD[23:16] (default)
Output
gpio_first[2][7] = 1 GPIO[39] Input/Output
sft_cfg13[8:4] = 5'b01101 ADC_DATA Input
sft_cfg2[3:2] = 3 UA0_TXD Output
sft_cfg3[13:12] = 2 TV_VSYNC Input/Output
sft_cfg14[10:8] = 3'b010 TV_VSYNC_SRGB Output
sft_cfg4[15:13] = 3'b010
TV_VSYNC_PC
Output
sft_cfg7[7:6] = 1 FL_PCMCIA_IOR_B Output
sft_cfg1[11:9] = 3'b101 INT1_11 Input
sft_cfg0[13:12] = 1 TV_LCD_G[3] Output
sfg_cfg15[5:3] = 3'b100 FM_GPIOB[4] Input/Output
sfg_cfg16[11:8] = 4'b0101 FM_GPIOB[11] Input/Output
sfg_cfg17[3:0] = 4'b0001 FM_GPIOB[18] Input/Output
sfg_cfg18[3:0] = 4'b1001 FM_GPIOB[33] Input/Output
(other) GPIO[39] Input/Output
Priority selection Function Dir
hw_cfg_chg[5]=1’b1 SDRAM data bus [23] Input/Output
gpio_first[2][8] = 1 GPIO[40] Input/Output
sft_cfg13[14:12] = 3'b001 AT_D[11] Input/Output
sft_cfg13[14:12] = 3'b100 AT_D[12] Input/Output
{sft_cfg20[0],sft_cfg7[5:4]} =
3'b001
656_DATA[0]
Output
{sft_cfg20[1],sft_cfg19[5:4]} =
3'b001
HD_DATA[0]
Output
{sft_cfg20[2],sft_cfg14[7:6]} =
3'b001
SRGB_DATA[0]
Output
sft_cfg0[13:12] = 1 TV_LCD_G[4] Output
sfg_cfg16[11:8] = 4'b0100 FM_GPIOB[11] Input/Output
sfg_cfg16[15:12] = 4'b0101 FM_GPIOB[12] Input/Output
sfg_cfg17[3:0] = 4'b0001 FM_GPIOB[17] Input/Output
sfg_cfg18[3:0] = 4'b1001 FM_GPIOB[34] Input/Output
(other) GPIO[40] (default) Input/Output
