HT-DV40H
8 – 34
D12 29 LVTTL B RGB24 interface bit-12 (B[2]) or GPIO_1_12(CCIR656-like link)
D13 28 LVTTL B RGB24 interface bit-13 (B[3]) or GPIO_1_13(CCIR656-like link)
D14 27 LVTTL B RGB24 interface bit-14 (B[4]) or GPIO_1_14(CCIR656-like link)
D15 26 LVTTL B RGB24 interface bit-15 (B[5]) or GPIO_1_15(CCIR656-like link)
D16 23 LVTTL Intput RGB24 interface bit-16 (B[6]) or CCIR656-like bit-0/ CCIR656-like bit-7
D17 22 LVTTL Intput RGB24 interface bit-17 (B[7]) or CCIR656-like bit-1/ CCIR656-like bit-6
D18 21 LVTTL Intput RGB24 interface bit-18 (R[0]) or CCIR656-like bit-2/ CCIR656-like bit-5
D19 20 LVTTL Intput RGB24 interface bit-19 (R[1]) or CCIR656-like bit-3/ CCIR656-like bit-4
D20 19 LVTTL Intput RGB24 interface bit-20 (G[0]) or CCIR656-like bit-4/ CCIR656-like bit-3
D21 18 LVTTL Intput RGB24 interface bit-21 (G[1]) or CCIR656-like bit-5/ CCIR656-like bit-2
D22 17 LVTTL Intput RGB24 interface bit-22 (B[0]) or CCIR656-like bit-6/ CCIR656-like bit-1
D23 16 LVTTL Intput RGB24 interface bit-23 {B[1]} or CCIR656-like bit-7/ CCIR656-like bit-0
IHS 119 LVTTL Intput RGB24 interface HSYNC
IVS 118 LVTTL Intput RGB24 interface VSYNC
Analog Video Output Interface ñ DAC
DAC0 97 Analog Output DAC analog red / Y output
DAC1 96 Analog Output DAC analog green / Pb output
DAC2 93 Analog Output DAC analog blue / Pr output
AHS 90 LVTTL Output Separate HSYNC signal (digital output)
AVS 89 LVTTL Output Separate VSYNC signal (digital output)
Audio Interface
MCLK 2 LVTTL Intput
Audio input Master Clock
(The supplied clock must be ìcoherentî with the input S/PDIF or I
2
S)
S/PDIF 9 LVTTL Intput S/PDIF audio input
SCK 3 LVTTL Intput I
2
S Serial Clock
WS 4 LVTTL Intput I
2
S Word Select
SD0 8 LVTTL Intput I
2
S Serial Data 0
SD1 7 LVTTL Intput I
2
S Serial Data 1
SD2 6 LVTTL Intput I
2
S Serial Data 2
SD3 5 LVTTL Intput I
2
S Serial Data 3
HDMI Interface
TX0+ 73 Analog Output TMDS output data pairs
TX0- 72 Analog Output
TX1+ 76 Analog Output TMDS output data pairs
TX1- 75 Analog Output
TX2+ 79 Analog Output TMDS output data pairs
TX2- 78 Analog Output
TXC+ 70 Analog Output TMDS output clock pairs
TXC- 69 Analog Output
HPD 48 LVTTL Intput Hot Plug Detect input
INT 108 LVTTL Output Interrupt output
DSCL 50 Schmitt Output DDC I2C Master Clock
DSDA 49 Schmitt B DDC I2C Master Data (Open drain output)
GPIO
GPIO_2_0 110 LVTTL B General-purpose Intput/Output
GPIO_2_1 111 LVTTL B General-purpose Intput/Output
GPIO_2_2 112 LVTTL B General-purpose Intput/Output
GPIO_2_3 88 LVTTL B General-purpose Intput/Output
External EEPROM Interface (I2C Address : A0)
KWP / NC 46 LVTTL Output Write Protect (NC for SPHE6500P/SPHE6502P)
KSCL / NC 45 LVTTL Output External EEPROM I2C Clock (NC for SPHE6500P/SPHE6502P)
KSDA / NC 44 LVTTL B External EEPROM I2C Data (NC for SPHE6500P/SPHE6502P)
Power Ground Pins
DVCC18
14,51,92,11
4,121,54,56,
58,62,64
Power
Digital power 1.8V
DGND
24,52,85,
109,120,10,
15,34,86,
107,123,57,
53,55,59,61,
63
Gnd
Digital GND
DVCC33
12,25,
43,91,115,
126,60
Power
Digital power 3.3V
HAVCC 71,77 Power HDMI analog power 3.3V
HAGND
68,74,80,65,
82,83
Gnd
HDMI analog GND
Mnemonic Pin# Type Dir. Description
