HT-DV40H
8 – 4
SPDC_OUT/
GPIO
57 Input/Output
Servo SPDC_OUT
SC_OUT/GPIO 58 Input/Output
Servo SC_OUT
SC1_OUT/GPIO 59 Input/Output
Servo SC1_OUT
Symbol Pin # Input/Output Description
Priority selection Function Dir
gpio_first[4][2] = 1
GPIO[66]
Input/Output
sft_cfg13[11:9] = 3'b001
AT_RESET_B
Output
sft_cfg13[11:9] = 3'b111
AT_ADR[2]
Output
sft_cfg13[14:12] = 3'b011
AT_D[1]
Input/Output
sft_cfg13[14:12] = 3'b101
AT_D[1]
Input/Output
sft__cfg13[14:12] = 3'b110
AT_D[1]
Input/Output
sft_cfg4[0] = 2
SPDC_OUT (default)
Input/Output
sft_cfg11[8:6] = 3'b100
TS_DATA[3]
Input/Output
sfg_cfg15[2:0] = 3'b011
FM_GPIOB[1]
Input/Output
sfg_cfg16[11:8] = 4'b1001
FM_GPIOB[10]
Input/Output
sfg_cfg17[11:8] = 4'b0010
FM_GPIOB[25]
Input/Output
sfg_cfg17[11:8] = 4'b0101
FM_GPIOB[21]
Input/Output
sfg_cfg17[11:8] = 4'b0110
FM_GPIOB[21]
Input/Output
sft_cfg8[5] = 1'b1
DATA_Cb_EXT[3]
Input
(other)
GPIO[66]
Input/Output
Priority selection Function Dir
gpio_first[4][3] = 1
GPIO[67]
Input/Output
sft_cfg13[11:9] = 3'b001
AT_DIOR_B
Output
sft_cfg13[11:9] = 3'b111
AT_ADR[0]
Output
sft_cfg13[14:12] = 3'b011
AT_D[14]
Input/Output
sft_cfg13[14:12] = 3'b101
AT_D[14]
Input/Output
sft__cfg13[14:12] = 3'b110
AT_D[14]
Input/Output
sft_cfg4[1] = 2
SC_OUT (default)
Input/Output
sft_cfg11[8:6] = 3'b100
TS_DATA[2]
Input/Output
sfg_cfg16[11:8] = 4'b1011
FM_GPIOB[11]
Input/Output
sfg_cfg16[15:12] = 4'b0011
FM_GPIOB[14]
Input/Output
sfg_cfg17[15:12] = 4'b0010
FM_GPIOB[26]
Input/Output
sfg_cfg18[3:0] = 4'b0101
FM_GPIOB[34]
Input/Output
sfg_cfg18[3:0] = 4'b0110
FM_GPIOB[34]
Input/Output
sft_cfg8[5] = 1'b1
DATA_Cb_EXT[2]
Input
(other)
GPIO[67]
Input/Output
Priority selection Function Dir
gpio_first[4][4] = 1
GPIO[68]
Input/Output
sft_cfg13[11:9] = 3'b001
AT_DIOW_B
Output
sft_cfg13[14:12] = 3'b011
AT_D[2]
Input/Output
sft_cfg13[14:12] = 3'b101
AT_D[2]
Input/Output
sft_cfg13[14:12] = 3'b110
AT_D[2]
Input/Output
sft_cfg4[2] = 2
SC1_OUT (default)
Input/Output
sft_cfg11[8:6] = 3'b100
TS_DATA[1]
Input/Output
sfg_cfg15[2:0] = 3'b011
FM_GPIOB[2]
Input/Output
sfg_cfg16[15:12] = 4'b1001
FM_GPIOB[12]
Input/Output
sfg_cfg17[11:8] = 4'b0101
FM_GPIOB[22]
Input/Output
sfg_cfg17[11:8] = 4'b0110
FM_GPIOB[22]
Input/Output
sfg_cfg18[3:0] = 4'b0010
FM_GPIOB[27]
Input/Output
sft_cfg8[5] = 1'b1
DATA_Cb_EXT[1]
Input
(other)
GPIO[68]
Input/Output
