HT-DV40H
8 – 9
GPIO 71 Input/Output
GPIO
GPIO 72 Input/Output
GPIO
Symbol Pin # Input/Output Description
Priority selection Function Dir
gpio_first[0][12] = 1 GPIO[12]
Input/Output
sft_cfg2[7:6] = 3 UA0_DTR_B
Output
sft_cfg13[11:9] = 3'b100
AT_ADR[2]
Output
sft_cfg13[14:12] = 3'b010 AT_D[1]
Input/Output
sft_cfg13[14:12] = 3'b011 AT_D[7]
Input/Output
sft_cfg13[14:12] = 3'b101
AT_D[7]
Input/Output
sft_cfg13[14:12] = 3'b110
AT_D[7] Output
{sft_cfg20[0],sft_cfg7[5:4]} = 3'b011
656_DATA[3] Output
{sft_cfg20[1],sft_cfg19[5:4]} = 3'b011 HD_DATA[3] Output
{sft_cfg20[2],sft_cfg14[7:6]} = 3'b011 SRGB_DATA[3]
Output
sft_cfg4[15:13] = 3'b001
TV_HSYNC_PC
Input
sft_cfg11[5:3] = 3'b010 EXT_TS_CLK
Input/Output
sfg_cfg15[2:0] = 3'b001 FM_GPIOB[3]
Input/Output
sfg_cfg15[15:12] = 4'b0011 FM_GPIOB[7]
Input/Output
sfg_cfg17[7:7] = 4'b0100 FM_GPIOB[20]
Input/Output
sfg_cfg17[11:8] = 4'b1000 FM_GPIOB[22]
Input/Output
sfg_cfg18[3:0] = 4'b0101 FM_GPIOB[27]
Input/Output
sfg_cfg18[3:0] = 4'b0110 FM_GPIOB[27]
Input/Output
(other) GPIO[12] (default)
Input/Output
Priority selection Function Dir
gpio_first[0][13] = 1 GPIO[13]
Input/Output
sft_cfg13[8:4] = 5'b00100 ADC_DATA
Input
sft_cfg2[7:6] = 3
UA0_RI_B
Input
sft_cfg13[11:9] = 3'b100 AT_ADR[1]
Output
sft_cfg13[14:12] = 3'b010 AT_D[13]
Input/Output
sft_cfg13[14:12] = 3'b011 AT_D[8]
Input/Output
sft_cfg13[14:12] = 3'b101
AT_D[8] Input/Output
sft_cfg13[14:12] = 3'b110
AT_D[8] Input/Output
{sft_cfg20[0],sft_cfg7[5:4]} = 3'b011 656_DATA[4] Output
{sft_cfg20[1],sft_cfg19[5:4]} = 3'b011 HD_DATA[4]
Output
{sft_cfg20[2],sft_cfg14[7:6]} = 3'b011
SRGB_DATA[4]
Output
sft_cfg4[15:13] = 3'b001 TV_VSYNC_PC
Output
sft_cfg11[5:3] = 3'b010 TS_FRAME_B
Input/Output
sft_cfg3[15:14] = 1 IOCHRDY
Input
{sft_cfg20[5:3],sft_cfg14[15:13]} =
6'b000001
INT0_7
Input
sfg_cfg15[5:3] = 3'b001 FM_GPIOB[4]
Input/Output
sfg_cfg16[3:0] = 4'b0011 FM_GPIOB[8]
Input/Output
sfg_cfg17[3:0] = 4'b0100 FM_GPIOB[17]
Input/Output
sfg_cfg17[11:8] = 4'b1000 FM_GPIOB[23]
Input/Output
sfg_cfg18[3:0] = 4'b0101 FM_GPIOB[28]
Input/Output
sfg_cfg18[3:0] = 4'b0110 FM_GPIOB[28]
Input/Output
(other) GPIO[13] (default)
Input/Output
