HT-DV40H
8 – 10
GPIO 73 Input/Output
GPIO
GPIO 75 Input/Output
GPIO
Symbol Pin # Input/Output Description
Priority selection Function Dir
gpio_first[0][14] = 1 GPIO[14] Input/Output
sft_cfg2[7:6] = 3
UA0_DCD_B
Input
sft_cfg13[11:9] = 3'b011
AT_RESET_B
Output
sft_cfg13[11:9] = 3'b100
AT_IORDY_B
Input
sft_cfg13[11:9] = 3'b101
AT_RESET_B
Output
sft_cfg13[11:9] = 3'b110
AT_RESET_B
Output
sft_cfg13[14:12] = 3'b010
AT_D[2]
Input/Output
{sft_cfg20[0],sft_cfg7[5:4]} = 3'b011
656_DATA[5]
Output
{sft_cfg20[1],sft_cfg19[5:4]} = 3'b011
HD_DATA[5]
Output
{sft_cfg20[2],sft_cfg14[7:6]} = 3'b011
SRGB_DATA[5]
Output
sft_cfg11[5:3] = 3'b010
TS_GNT_B
Input/Output
sft_cfg2[9:8] = 3
FL_PCMCIA_WAIT_B
Input
sft_cfg7[11:8] = 4'b0001
VGA_CLK
Input
sft_cfg1[11:9] = 3'b001
INT1_11
Input
sfg_cfg15[2:0] = 3'b101
FM_GPIOB[2]
Input/Output
sfg_cfg15[2:0] = 3'b110
FM_GPIOB[2]
Input/Output
sfg_cfg15[8:6] = 3'b001
FM_GPIOB[5]
Input/Output
sfg_cfg17[11:8] = 4'b0100
FM_GPIOB[23]
Input/Output
sfg_cfg17[11:8] = 4'b1000
FM_GPIOB[24]
Input/Output
sfg_cfg17[15:12] = 4'b0011
FM_GPIOB[26]
Input/Output
(other)
GPIO[14] (default)
Input/Output
Priority selection Function Dir
gpio_first[0][15] = 1
GPIO[15]
Input/Output
sft_cfg13[3:0] = 4'b0110 IEC_RX
Input
sft_cfg13[8:4] = 5'b00101 ADC_DATA
Input
sft_cfg13[11:9] = 3'b001 AT_ADR[1]
Output
sft_cfg13[11:9] = 3'b010 AT_RESET_B
Output
sft_cfg13[11:9] = 3'b011 AT_DMACK_B
Output
sft_cfg13[11:9] = 3'b100 AT_DIOR_B
Output
sft_cfg1[8:6] = 3'b001 FL_MEM_CSALL_B
Output
{sft_cfg20[0],sft_cfg7[5:4]} = 3'b011 656_DATA[6]
Output
{sft_cfg20[1],sft_cfg19[5:4]} = 3'b011 HD_DATA[6]
Output
{sft_cfg20[2],sft_cfg14[7:6]} = 3'b011 SRGB_DATA[6]
Output
sft_cfg11[5:3] = 3'b011 TS_DATA[0]
Input/Output
sysclk_sel[4] = 1'b1 EXT_CLK
Input
sft_cfg7[11:8] = 4'b0010 VGA_CLK
Input
sft_cfg1[11:9] = 3'b100 INT1_11
Input
{sft_cfg20[5:3],sft_cfg14[15:13]} =
6'b000100
INT0_7
Input
sfg_cfg15[2:0] = 3'b101 FM_GPIOB[3]
Input/Output
sfg_cfg15[2:0] = 3'b110 FM_GPIOB[3]
Input/Output
sfg_cfg15[11:9] = 3'b001 FM_GPIOB[6]
Input/Output
sfg_cfg17[3:0] = 4'b0011 FM_GPIOB[18]
Input/Output
sfg_cfg17[11:8] = 4'b0100 FM_GPIOB[22]
Input/Output
sfg_cfg17[11:8] = 4'b1000 FM_GPIOB[25]
Input/Output
sft_cfg7[13:12] = 3 CLK54_OUT
Output
sft_cfg9[14:13] = 3 EXT_CLK48
Input
(other) GPIO[15] (default)
Input/Output
