Sharp HT-SB107 User Manual

EN
Accessories
• 1x User guide
• 1x Warranty lea et
• 1x Remote control
• 2x AAA battery
• 1x Power adapter
• 1x AC plug for power adapter
• 4x Silicone feet
• 1x Wall mount  xings
Controls
1 2
3
4
5
1. Indicator light
• Red: In STANDBY mode.
• Blue: In Bluetooth mode.
• Green: In LINE IN mode.
• Yellow: In Optical mode.
• Cyan: In HDMI ARC mode.
• Purple: In USB mode.
2. Remote sensor
3.
Standby – Switch the unit be-
tween ON and STANDBY mode.
4.
Source – Select the play function.
5. Volume +/- – Increase/decrease the
volume level.
Inputs/Outputs
3
4
1
2
5
1. ARC Socket – Connect to a TV via
HDMI cable.
2. USB Socket – Used to connect with
the USB  ash disk.
3. LINE IN Socket – Connect to an
external audio device.
4. OPTICAL Socket – Opticial input
jack.
5. DC IN Socket – Socket for connect-
ing power adapter (DC 18V/2,0A).
Remote control
1. – Switch the unit between ON and
STANDBY mode.
2.
– Select the Bluetooth mode.
Press and hold to activate the
pairing function in Bluetooth mode
or disconnect the existing paired
Bluetooth device.
3.
– Select the play function.

Sharp HT-SB107 Specifications

General

RMS rated power	90 W
Audio output channels	2.0 channels
Audio Return Channel (ARC)	Yes
Bluetooth version	4.2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Digital audio optical in	1
Certification	CE, REACH/PAH/SCCP
Product color	Black
Audio formats supported	MP3, WAV
Subwoofer included	-
Soundbar power consumption	20 W
Power consumption (standby)	0.5 W
Sustainability certificates	RoHS
Package depth	155 mm
Package width	740 mm
Package height	124 mm
Package weight	1900 g
Number of speakers	2

Weight and Dimensions

Depth	88 mm
Width	652 mm
Height	64 mm
Soundbar weight	1300 g
