HT-SB60
Falling prevention
● Safety wires (not supplied) are useful to prevent the sound bar from falling off.
● 2 persons are required to perform this procedure.
When mounting on the wall
1 Loop the safety wires (not supplied) into each hole
of the wall mount angle as shown.
2 Loop the safety wires from wall mount angle into
each hole of sound bar as shown.
Wall surface
Wall surface
3 Align and fix the sound bar to wall mount angle.
4 Tie the safety wires tightly.
Wall surface
Wall surface
When placing on the shelf/table
Loop the safety wires (not supplied) into each hole as shown
and tie the safety wires to the LCD TV stand.
