HT-SL50
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
[9] CABINET PARTS / SUBWOOFER PARTS
201 GiTARA822AWSA AH Rear Panel
202 LANGT0042AWFW AC Bracket, PWB Support
203 LBSHC0002AWZZ AD Bushing, AC Power Supply Cord
204 LCHSMA110AWFW AQ Chassis, Main
205 PCUSGA182AWZZ AD Cushion, Heat Sink
206 PRDARA224AWFW AN Heat Sink, IC
! 207 QACCBA008AW00 AX AC Power Supply Cord [ For U.K. ]
! 207 QACCEA001AW00 AP AC Power Supply Cord [ For Europe ]
208 TSPC-B472AWZZ AD Label, Specification [ For Europe ]
208 TSPC-B478AWZZ AD Label, Specification [ For U.K. ]
209 92LNBAND1318A AA Nylon Band
601 LX-JZ0010AFF7 AB Screw, Special
602 LX-JZ0044AWF8 AB Screw, Special
603 XEBY830P10000 AB Screw, M3 X 10mm
604 XHBY740P10000 AB Screw, M4 x 10mm
605 XHBY830P08000 AB Screw, M3 X 8mm
606 XJBY730P08000 AA Screw, M3 X 8mm
607 XJBY830P06000 AB Screw, M3 X 6mm
608 XMBY835P12000 AC Screw, M3.5 x 12mm
901 CWAKPA028AW01 AR Net Frame Ass'y
902 GBOXSA240AW01 BM Wooden Box Ass'y
903 GCOVAA293AWSA AH LED Indicator
904 HPNLSA104AWSA AZ Front Panel
905 LBNDZA001AWZZ AE Cable Tie
906 PCUSSA182AWZZ AE Cushion, Port
907 PCUSSA193AWZZ AF Sound Absorber
908 PCUSSA195AWZZ AE Cushion
909 PDUC-A109AWSA AH Paper Duct
910 PFLT-A171AWZZ AE Felt
911 QCNWNB566AWPZ AQ Lead Wire Ass'y
912 QCNWNB567AWPZ AS Lead Wire Ass'y
913 XMBY740P16000 AC Screw, M4 x 16mm
SP1 RSP-ZA346AWZZ BD Woofer
[10] ACCESSORIES / PACKING PARTS
1 B3CPSB50//2 BV Sound Bar Ass'y
2 GiTAUA004AW01 AM Subwoofer Stand Ass'y
3 GITAUA012AWSB AN Sound Bar Stand
4 LANGKA225AW01 AM Wall Mount Angle Ass'y ( 2pcs/pack)
5 PCUSGA189AWZZ AB Sound Bar Foot Cushion
6 PCUSSA190AWZZ AE Sound Bar Stand Cushion
7 QCNWGA062AWPZ AN Audio Cable
8 QCNWGA064AWPZ AP RCA Cabe
9 QCNWGA065AWPZ BA HDMI Cable
10 QCNWHA043AW01 AS Speaker Wire Assy
11 SPAKAA311AWZZ AM Packing Add, Top
12 SPAKAA312AWZZ AN Packing Add, Bottom
13 SPAKCA864AWZZ AV Packing Case
14 SPAKP0026AWZZ AB Polyethylene Bag, AC Cord [ For U.K. only ]
15 SSAKAA011AWZZ AB Polyethylene Bag, Accessories
16 SSAKHA197AWZZ AE Polyethylene Bag, Unit
17 TCAUHA026AWZZ AE Paper Pattern
18 TGAN-3170UMZZ AE Warranty Card [ For U.K. only ]
19 TiNSEA354AWZZ AE Operation Manual [ For U.K. ]
19 TiNSZA904AWZZ AM Operation Manual [ For Europe ]
20 TiNSEA355AWZZ AC Quick Guide [ For U.K. ]
20 TiNSZA927AWZZ AF Quick Guide ( Deutsch & Francais ) [ For Europe ]
21 TiNSZA942AWZZ AF Quick Guide ( Espanol & Svenska ) [ For Europe ]
22 TiNSZA943AWZZ AF Quick Guide ( Italiano & Nederlands ) [ For Europe ]
23 TiNSZA944AWZZ AF Quick Guide ( Portugues & Suomi ) [ For Europe ]
24 TiNSZA952AWZZ AF Quick Guide ( English & Polski ) [ For Europe ]
[11] P.W.B. ASSEMBLY
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
REMARK
(interchangeable)
DESCRIPTION
PWB-A 92LPWB8132MANS - S Category Main
!
PWB-B RUiTZA041AWZZ BK X Category SMPS
PWB-C 92LPWB8131HDMS - S Category HDMI
NOTE: FOR CABINET PARTS, ITEM NO. ARE 2XX AND 6XX
FOR SUBWOOFER PARTS, ITEM NO. ARE 9XX
